Allen-Bradley 1336 FORCE User Manual

Chapter 2
Installation/Wiring
2–2
Figure 2.2. IP20 (NEMA Type 1) Dimensions – Frames B and C
C Max.
D
A
Y
CC
E
B
Z
BB
AA
All Dimensions in Millimeters and (Inches)
All Weights in Kilograms and (Pounds)
Knockouts
3–Dual Size, 1–Fixed
28.6/34.9, 22.2
(1.125/1.375, 0.875)
28.6/34.9, 22.2
(1.125/1.375, 0.875)
Shipping
Weight
22.7 kg
(50 lbs.)
38.6 kg
(85 lbs.)
CC
71.9
(2.83)
71.9
(2.83)
Frame
1
Reference
B1, B2
C
A
276.4
(10.88)
301.8
(11.88)
B
476.3
(18.75)
701.0
(27.60)
C Max.
225.0
(8.86)
225.0
(8.86)
D
212.6
(8.37)
238.0
(9.37)
E
461.0
(18.15)
685.8
(27.00)
Y
32.00
(1.26)
32.00
(1.26)
Z
7.6
(0.30)
7.6
(0.30)
AA
131.1
(5.16)
131.1
(5.16)
BB
180.8
(7.12)
374.7
(14.75)
7.0 (0.28)
7.0 (0.28)
12.7 (0.50)
12.7 (0.50)
Mounting Holes (4)
Knockouts
(Location Will Vary with HP)
