Allen-Bradley 1336 FORCE User Manual

Chapter 1
Introduction
1–3
• Encoderless Speed Regulation – 1% of Top Speed over a 40:1 Speed
Range.
• Accel/Decel – Independently programmable accel and decel times.
Program from 0 to 6553 seconds in 0.1 second increments.
• Current Limit – Independent Motoring and Regenerative Limit
• Inverse Time Overload Capability – Class 20 protection with
speed–sensitive response. Adjustable from 0–200% of rated output
current in 3 speed ranges – 2:1, 4:1 & 10:1. UL Certified – Meets
NEC Article 430.
Options
• Standard Adapter Board which provides:
– 2 Analog Inputs +/–10V
– 2 Analog Outputs +/– 10V
– One 4–20mA input
– One 4–20mA output
– 5 or 12 vdc pulse input
– +/– 10V reference voltages
– At Speed, Run, Fault and Alarm contacts
• PLC Communication Adapter Board which provides:
– 4 Analog Inputs +/–10V
– 4 Analog Outputs +/– 10V
– +/– 10V Reference voltages
– RIO/DH
TM
+ Communications (2 channels selectable)
– Function Blocks
• DriveTools
TM;
PC Windows
TM
based programming software
compatible with the 1336 FORCE Drive and also other
Allen–Bradley 1336 and 1395 products.
• Dynamic Braking
• AC Motor Contactor
Protective Features The 1336 FORCE Drive incorporates the following protective measures:
• Programmable Motor Overload Protection (I
2
T) investigated by UL
to comply with NEC Article 430.
• Programmable Inverter Overload Protection (IT)
• Overspeed Detection, even when operating as a torque follower.
• Programmable Stall Detection
• Peak output current monitoring to protect against excessive current
at the output due to a phase to ground or phase to phase short.
• Ground fault monitoring
• DC Bus Voltage monitoring to protect against under/over voltage
conditions.
• Power Structure Heatsink Temperature Monitoring

Allen-Bradley 1336 FORCE Specifications

General

Brand	Allen-Bradley
Model	1336 FORCE
Category	Controller
Language	English
