Allen-Bradley 1336 FORCE User Manual

Appendix B
CE Conformity
B–2
Filter Selection:
Fi
lter
C
atalo
g
Number
T
h
ree
-Ph
ase
Volts
Used with . . .
F
rame
Reference
1336-RFB-30-A 200-240V 1336T-A001 - A003 A
380-480V 1336T-B001 - B003 B
1336-RFB-27-B 200-240V 1336T-A007 B
380-480V 1336T-B007 - B015 B
1336-RFB-48-B 200-240V 1336T-A010 - A015 B
380-480V 1336T-B020 - B030 B
1336-RFB-80-C 200-240V 1336T-A020 - A030 C
380-480V 1336T-BX040 - BX060 C
1336-RFB-150-D 200-240V 1336T-A040 - A050 D
380-480V 1336T-B060 - B100 D
1336-RFB-180-D 200-240V 1336T-A060 D
380-480V 1336T-B125 - BX150 D
1336-RFB-340-E 200-240V 1336T-A075 - A125 E
380-480V 1336T-B150 - B250 E
1336-RFB-475-G 380-480V 1336T-BX250 - B350 G
1336-RFB-590-G 380-480V 1336T-B400 - B450 G
1336-RFB-670-G 380-480V 1336T-B500 - B600 G
Not Available 380-480V 1336T-B700 - B800 H
EMC Enclosure Kit Selection
F
rame
Enclosure Kit Catalog Number
F
rame
R
e
f
erence
200-240V Rating
380-480V Rating 500-600V Rating
B 1336-AE4 1336-AE4 1336-AE4
C 1336-AE5 1336-AE5 1336-AE5
D 1336-AE6 1336-AE6 1336-AE6
E 1336-AE7 1336-AE7 1336-AE7
F–H Not Available
RFI Filter Installation
!
ATTENTION: To prevent electrical shock, disconnect the
power source before installing or servicing.
Important: Refer to the instructions supplied with the filter for details.
The RFI filter must be connected between the incoming AC supply line
and the drive input terminals.
RFI Filter Leakage Current
The RFI filter may cause ground leakage currents. Therefore a solid
ground connection must be provided as shown in the electrical
configuration scheme shown on the following page.
Filter
