Allen-Bradley 1336 FORCE User Manual

Chapter 6
Troubleshooting
6–18
Figure 6.6
Parameter 83 (VP Configurable Fault Status)
Feedback Loss
Inverter Overtemp Pending
Motor Overtemperature Tripped
Motor Overload Pending – IIT
Motor Overload Trip – IIT
Motor Stalled
External Fault
RMS Fault
NOT USED
Parameter Limit
Math Limit
Dynamic Brake Resistor Overtemperature
AC Motor Contactor Failure
Inverter Overload Pending (IT)
Drive–to–Drive Communication Fault
Inverter Overload Trip (IT)
O O O O O O O O. O O O O O O O O
Bit#
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Figure 6.7
Parameter 89 (VP Warning/None Configuration Select (bits))
O O O O O O O O. O O O O O O O O
Bit#
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
This word parameter indicates conditions detected by the Velocity Processor (VP) that have been configured to report as
a Drive fault condition. Each configuration bit matches the bit definitions of Parameters 85, 88 and 89. When a bit is set
to “1”, the corresponding condition in the Drive is true, otherwise the condition is false.
Feedback Loss
Inverter Overtemp Pending
Motor Overtemperature Tripped
Motor Overload Pending – IIT
Motor Overload Trip – IIT
Motor Stalled
External Fault
RMS Fault
NOT USED
Parameter Limit
Math Limit
Dynamic Brake Resistor Overtemperature
AC Motor Contactor Failure
Inverter Overload Pending (IT)
Drive–to–Drive Communication Fault
Inverter Overload Foldback (IT)
This word parameter indicates conditions detected by the Velocity Processor (VP) that will be reported as either a drive
fault or warning or not reported at all (ignored). Each configuration bit matches the bit definitions of Parameters 83, 85
and 88. When a bit is set to “1”, the corresponding condition in the Drive will be reported as configured by parameter 88.
When the bit is set to “0”, the condition is not reported.
