WIRING DIAGRAM KEY -
1) Generator
2) CDI
3) Spark plug
4) HV coil
5) Voltage regulator
6) Battery
7) Starter
8) Start relay
9) Front stoplight switch
10) Rear stoplight switch
11) 2 stroke oil reserve warning light
12) Automatic starter
13) Fuel level sensor
14) Rear right direction indicator
15) Rear light
16) Rear left direction indicator
17) Left dimmer switch
18) Right dimmer switch
19) Ignition switch / steering lock
20) Control diode
21) License plate light
22) Blinking
23) Dashboard
24) Direction indicators warning light
25) 2 stroke oil reserve warning light
26) Dashboard lights
27) Fuel level instrument
28) Low fuel warning light
29) High beam warning light
30) Front parking light
31) Front right direction indicator
32) Front left direction indicator
33) Front light
34) High/low beam bulb
35) Horn
36) Pick up
37) Fuses
38) Multiple connectors
39) Rear parking light / stoplight / license plate light
40) √
41) Parking light and low beam warning light
CABLE COLOURS
Ar orange
Az light blue
B blue
Bi white
G yellow
Gr grey
M brown
N black
R red
V green
Vi purple
Ro pink
