14
CALIFORNIA EVAPORATIVE
EMISSION SYSTEM
FOR STATE OF CALIFORNIA ONLY.
1) Fuel tank
2) Fuel tank breathes line (to valve)
3) Purge/roll over valve
4) Breathes line (tee)
5) Tee
6) Breathes line (to canister)
7) Float bowl breathes line
8) Carbon canister
9) Carbon canister vent
10) Drain line
11) Manifold Air box
12) Manifold ported vacuum port
13) Air box
14) Carburetor
MC150
MC150
1
2
9
5 10 4
12
3
6
8
7 14 11 13
