115
use and maintenance Mojito 50 - 150
USA
WIRING DIAGRAM KEY -
1) Fuel level sensor
2) Multiple connectors
3) Low fuel warning light
4) Direction indicators warning light
5) Parking light warning light
6) Dashboard lights
7) High beam warning light
8) Oil pressure warning light
9) Fuel level instrument
10)Dashboard
11)Ignition keyswitch
12)Left dimmer switch
13)Horn
14)Right dimmer switch
15)Jumper (Europe only)
16)Blinking (US only)
17)-
18)Rear direction indicator RH
19)Two-position rear lamp
20)Rear light
21)Rear direction indicator LH
22)License plate light
23)Front stoplight switch
24)Rear stoplight switch
25)Start relay
26)Starter
27)Battery
28)Fuses
29)-
30)Carburetor heater
31)Coil
32)Spark plug
33)C.D.I.
34)Pick up
35)Three-phase generator
36)Oil pressure sensor
37)Automatic starter
38)Regulator
39)Front direction indicator RH
40)Parking light lamp
41)Two position front lamp
42)Front light
43)Front direction indicator LH
CABLE COLOURS
Ar orange
Az light blue
B bluE
Bi white
G yellow
Gr grey
M brown
N black
R red
V green
Vi purple
Ro pink
MC150
APRum_MOJ50_150#02_####.book Page 115 Tuesday, August 3, 2004 9:25 AM
