INSTRUMENT AND INDICATOR TABLE
Description Function
Right direction indicator warning light
()
It blinks when the direction indicators are on.
2 stroke oil reserve warning light
()
It comes on when the ignition switch is in position ≈∆ and the start push button ≈∆ is pressed, thus
checking the proper functioning of the bulb. If the light does not come on during the starting, provide for
replacing the bulb.
If the warning light comes on and does not go out after the start push button “ ”
has been released, or if it comes on during normal functioning, this means that:
the 2 stroke oil reserve is being used; in this case, top up the 2 stroke oil tank, see page 46 (2
STROKE OIL);
the engine oil pressure in the circuit is insufficient. In this case stop the engine immediatly and
contact on Aprilia Official Dealer.
Engine oil pressure warning light
()
It comes on every time the ignition switch is brought to position
≈∆
and the engine is not running, thus testing
the correct operation of the bulb. If during this phase the lamp does not turn on, it must be replaced.
The warning light must go off when the engine is running.
If the warning light comes on during the normal running of the engine, this
means that the oil pressure in the circuit is insufficient. In this case,
immediately stop the engine and contact your aprilia Official Dealer.
Total kilometres odometer
It indicates the total number of kilometres covered.
Speedometer
It indicates the driving speed.
Parking light and low beam warning light
()
It comes on when the lights are on.
High beam warning light ( )
It comes on when the headlight is in high beam position.
Low fuel warning light ( ) It comes on when the quantity of fuel left in the tank is about 0.5gal (2
).
Fuel level indicator( ) It indicates the approximate fuel level in the tank.
CAUTION
M50 MC50
MC150
MC150
CAUTION
