Aritech 2X-AF2-FB-PRT-P Installation Manual

Chapter 3: Configuration and commissioning
2X-A Series Installation Manual 95
Panel activation key
Note: See your PAK registration guide for more details on how to register or
unregister purchased PAKs.
Select Panel Activ. Key to register or unregister panel activation keys (PAKs).
PAKs are used to extend the default functionality of the control panel - increasing
the network capability, enabling additional protocols, etc. A list of available PAKs
is shown in the table below.
Table 43: Panel activation keys
PAK
Description
2010
-2-PAK-NET128 Increases the network capability to 32 nodes and 128 loops [1]
2010
-2-PAK-NET256 Increases the network capability to 64 nodes and 256 loops [1]
2010
-2-PAK-RMSDK Enables custom event reporting and command control using the
Edwards software development kit (SDK)
2010
-2-PAK-RMOH Enables the Contact ID protocol over Ethernet
2010
-2-PAK-RMBN Enables the BACnet protocol over Ethernet
2010
-2-PAK-RMMB Enables the Modbus protocol over Ethernet
2010
-2-PAK-900 Enables the 900 Series protocol
2010
-2A-PAK-HPL Enables the high powered loop [2]
[1] The default network capability with no PAK installed is 32 nodes and 32 loops.
[2] Increases the maximum loop output from 500 mA to 800 mA.
