Chapter 3: Configuration and commissioning
2X-A Series Installation Manual 117
Activation configuration
Select Activation configuration options to configure the activation delays for
output groups, investigation times, and general sounders behaviour (sounder
silencing and second stage usage).
Note: This option is not available on repeater panels.
Delay configuration options are shown in the table below.
Table 61: Activation configuration options
Description
Configures the activation of sounder groups with zones in alarm. A
warning delay can also be configured if the second stage delay option is
required.
Configures the activation of fire routing groups with zones in alarm.
Configures the activation of fire protection groups with zones in alarm.
Configures the activation of program groups with zones in alarm.
Configures the activation of output groups for each individual zone in
alarm. For each zone, a different output group activation delay (including
no activation) can be assigned for each configured output group.
Configures sounder silence disable time, maximum acknowledge time or
extended fire routing delays, and warning time for second stage
applications.
Sounder, fire routing, fire protection, and program output group delays
Select an output group type to configure delays (including no activation) for
sounder, fire routing, fire protection, and program output groups for all zones.
These output groups can be configured individually or all output group types at
the same time. All zones are programmed with the same setting: global delay or
no activation.
Configurable options for output group delays are shown in the table below.
Table 62: Configurable options for output group delays
Description
Output group selection (all output groups of the type selected or a
single output group of the type selected)
Output group activation (yes or no)
The delay (in minutes and seconds)
The warning delay (in minutes and seconds)
[1] Sounder output group delays only.
