Chapter 3: Configuration and commissioning
86 2X-A Series Installation Manual
Expansion board configuration
Select Expansion boards to add an installed expansion board to the control panel
configuration.
Note: If the installed expansion board firmware is not compatible with the control
panel, a warning message is displayed.
The available expansion boards are shown in the table below.
Table 34: Available expansion boards
Option
Description
LB
Loop board [1]
NB
Network board [2]
ZIC
Zone LED indicator board
PIB
Peripherals interface board
DACT
DACT board
[1]
Use only 2X-A-LB loop boards (older loop boards are not compatible for use with 2X-A
control panels
).
[2] By default repeater panels have the network board configured as installed.
To add an expansion board:
1. Select Panel setup from the Main menu.
2. Select Expansion boards.
3. Select the expansion board that you want to add, and then select YES.
4. Press F4 (Enter), and then press F1 (Back).
5. Press F1 (Save), F3 (Apply), F4 (Discard), or F2 (Exit).
Remember to apply saved settings from the Main menu.
If an installed expansion board is not detected by the control panel, a system
fault is indicated.
