Chapter 3: Configuration and commissioning
90 2X-A Series Installation Manual
Printer configuration
Select Printer configuration to configure internal, external, or terminal printers,
where available. Configuration options are shown in the table below. By default,
all printer configuration options are disabled.
Table 35: Printer configuration options
Option
Description
Used
Configures the printer status (used or not used)
RportMd [1]
Configures the external printer for report printing
NWEvent [2]
Configures the printing of system events for all control panels in the
network
Alarm [2]
Configures the printing of alarm events
Fault [2]
Configures the printing of fault events
Cond [2]
Configures the printing of condition events
StatCH [2]
Configures the printing of status change events (for example, inputs
and outputs)
BaudR [1]
Configures the printer baud rate
[1] This option is not available for internal printers.
[2] When RportMd is checked, these system events are not printed.
To change the configuration:
1. Select Panel setup from the Main menu, and then select Printer config.
2. Select Int printer config, Ext printer config, or Terminal config.
3. Select and check the check box for the options that you want to enable.
4. Press F4 (Enter), and then press F1 (Back).
5. Press F1 (Save), F3 (Apply), F4 (Discard), or F2 (Exit).
Remember to apply saved settings from the Main menu.
