Aritech 2X-AF2-FB-PRT-P Installation Manual

Chapter 5: Technical specifications
2X-A Series Installation Manual 139
Power supply specifications
Mains voltage
240/110 VAC +10% −15%
Mains frequency
50/60 Hz ±5%
Mains current
4 A power supply
6 A power supply
10 A power supply
1.2 A max. at 240 VAC
1.9 A max. at 110 VAC
1.6 A max. at 240 VAC
2.8 A max. at 110 VAC
<4.0 A max. at 240 VAC
<4.0 A max. at 110 VAC
CIE input voltage and current (mains on)
4 A power supply
6 A power supply
10 A power supply
24 VDC, 4 A
24 VDC, 5.8 A
27.8 VDC, 10 A
CIE input voltage
(mains off) 21 to 29 VDC
Maximum ripple at full load
150 mVpp
Note:
Ripple and noise are measured at 20 MHz of
bandwidth by using a 12-inch twisted-pair wire
terminated with a 0.1 µF and 47 µF parallel
capacitor.
Mains fuse
T 4A 250V at 240 VAC
T 4A 250V at 110 VAC
Typical control panel current consumption
(with no devices connected)
One-loop control panel
Two-loop control panel
Two-loop control panel with printer
Repeater panel
180 mA at 24 VDC
250 mA at 24 VDC
315 mA at 24 VDC
110 mA at 24 VDC
Typical expansion board current
consumption
Network board
DACT board
Loop board [1]
Peripherals boards [1]
2010-2-PIB
2010-2-PIB-8I
2010-2-PIB-8O
2010-2-PIB-8I8O
Zone LED boards
20/24-zones
40-zones
50 mA at 24 VDC
45 mA at 24 VDC
120 mA at 24 VDC
26 mA at 24 VDC
25 mA at 24 VDC
16 mA at 24 VDC
26 mA at 24 VDC
12 mA at 24 VDC
14 mA at 24 VDC
Quiescent current (Imax a) [2]
4 A power supply
6 A power supply
10 A power supply
2.5 A max. at 24 VDC
2.5 A max. at 24 VDC
2.5 A max. at 27.6 VDC
Alarm current (Imax b) [3]
4 A power supply
6 A power supply
10 A power supply
4 A max. at 24 VDC (batt. charger disconnected)
5.8 A max. at 24 VDC (batt. charger disconnected)
7.2 A max. + 2.8 A for batt. charger (batt. charger
NOT disconnected) at 27.6 VDC
