Chapter 3: Configuration and commissioning
128 2X-A Series Installation Manual
Table 68: Remote disable/enable – configuring Channel data
Description
Devices with only a single input or output (detectors, manual call
points, sounders). This is the default setting.
Inputs 1 to 4 for I/O modules.
Outputs 1 to 4 for I/O modules.
Tests
Diagnostics
Select Diagnostics for tools to support troubleshooting during installation. The
diagnostics tests available are shown in the table below.
Table 69: Diagnostics options
Description
Polls loop devices and retrieves raw data for device diagnostics.
Important: This option alters the normal detection scan to only poll the
device under test. This means that no alarms are reported by the
system while this test is being performed.
Displays current consumption values for the control panel outputs
Displays parameters for the control panel power supply and batteries
Displays the voltage and current consumption values for the control
panel loops
[1] Includes VIN1 and VIN2 values for compact repeaters.
To activate a diagnostics test:
1. Select Test in the Main menu, and then select Diagnostics.
2. Select the diagnostics test you require.
If the individual device test is selected, enter the loop and address details for
the device to be inspected (for example, 1.089 for device 89 on loop 1).
3. When the test is completed, exit the diagnostics menu to return the control
panel to normal operation.
