Chapter 3: Configuration and commissioning
2X-A Series Installation Manual 109
Description
Manual call point alarm.
This input type can be used for connecting to aspirating detector Fire2
outputs.
Prealarm (unlatched).
This input type can be used for connecting to aspirating detector Action
outputs.
Activation resets the panel remotely. To reset again, the input must be
deactivated, and then activated again.
External fault. Activation generates a latched fault event indicated as an
external fault.
Day mode. When this input is activated, the control panel switches to
day mode until the next scheduled night mode change (or until the
output is deactivated).
Night mode. When this input is activated, the control panel switches to
night mode until the next scheduled day mode change (or until the
output is deactivated).
Fault Warning Output Open Supervision. By using a 2010-FS-EOL end-
of-line device, the control panel can supervise the open circuit condition
of the Fault Warning output.
Fire routing acknowledgement (type 1). The input receives
acknowledgement from the remote monitoring equipment that the fire
routing signal was received correctly. If the acknowledgement is not
received within 100 seconds of fire routing activation, the control panel
reports a fire routing fault.
Fire routing acknowledgement (type 2). The input receives
acknowledgement from the remote monitoring equipment that the fire
routing signal was received correctly. If the acknowledgement is not
received within 240 seconds of fire routing activation, the control panel
reports a fire routing fault.
Fire protection acknowledgement (type 1). The input receives
acknowledgement from remote fire protection equipment. If the
acknowledgement is not received within 100 seconds of fire protection
activation, the control panel reports a fire protection fault.
Fire protection acknowledgement (type 2). The input receives
acknowledgement from remote fire protection equipment. If the
acknowledgement is not received within 240 seconds of fire protection
activation, the control panel reports a fire protection fault.
Fire protection fault. Used to indicate remote faults in fire protection
equipment.
Disable FBF sounder button (Akustische Signale). Used to interface to
remote FBF equipment to disable or enable sounders.
Manual call point alarm (sprinkler).
Manual call point alarm (“hausalarm”).
Keyswitch access. Activation enables the Operator access level for the
control panel (no password required). Only one input per control panel
can be configured to use this mode.
