R5906112 /15 UDX180
3D Active eye wear (optional), passive circular (optional); 2 flash up to
200Hz*; optional Dual Eye Point 240Hz
Inputs Single HDBaseT; HDMI2.0 (HDCP2.2, HDR10); DP 1.2 (HDCP 1.3); Quad
3G/12G SDI / BarcoLink ULTRA
Optional Inputs Quad DP1.2 / Fiber SFP
Input resolutions From NTSC up to 4K (4,096 x 2,560)
refresh rates:
24hz to 120hz 4K/4KUHD (4096 x 2160/ 3860 x 2400) to 240hz WQXGA
(2560 x 1600)
Max. pixel clock 600 Mhz
Software tools Projector Toolset + Android app + iOS app
Control XLR wired + IR, RS232, Wifi (opt), GSM (opt)
Network connection 10/100 base-T, RJ-45 connection, Wifi (optional)
Power requirements 120-160V (reduced power)/ 200-240V (+/- 10%), 20A, 50-60Hz (reduced
power on 110v)
Max. power consumption 2,450W nom/2,650W max. / STBY less than 10W
Noise level (typical at 25°C/
77°F)
52dB(A)
Operational ambient
temperature
0°-40°C/ 32°-104°F (45°C reduced power)
Operational humidity 0-80% (non condens)
Dissipation BTU Max. 8,342 BTU/h
Dimensions (WxLxH) 660 x 830 x 350 mm (25.98 x 32.67 x 13.77")
Shipping Dimensions (WxLxH) 800 x 1200 x 685 mm / 31.49 x 47.24 x 26.96 inches
Weight 92kg (202 lbs)/shipping weight from factory: 110kg (242 lbs)
Standard accessories Power cord, wireless/XLR wired rugged remote control
Certifications Compliant with UL60950-1 and EN60950-1, complies with FCC rules &
regulations part 15 Class A and CE EN55022 Class A, Rhos
Warranty 3 years
* Software upgradeable, please contact your local authorized Barco sales
representative
A.4 Specifications of the UDX-4K22
Specifications
Projector type 4K UHD 3-chip DLP digital projector
Technology 0.9" DMD™ x3
Resolution 3,840 x 2,400 (4K UHD) / 2,560 x 1,600 (native) / 5,120 x 3,200
(processing)
Brightness 20,000 (WQ)/19,000 (4K UHD) center lumens* // 19,000 (WQ)/18,000 (4K
UHD) ansi lumens // 21,500 ISO
