R5906112 /15 UDX184
A.6 Specifications of the UDX-W32
Specifications
Projector type WUXGA 3-chip DLP digital projector
Technology 0.96" DMD™ x3
Resolution 1,920 x 1,200
Brightness 32,000 center lumens/ 31,000 ansi lumen / 34,000 ISO
Contrast ratio Full field 2200:1 / Barco Dyna Black 20000:1
Brightness uniformity 95%
Aspect ratio 16:10
ScenergiX Horizontal and vertical edge blending
Lenses TLD+ 0.37, 0.65-0.85, 0.73:1 ; 1.2:1 ; 0.8-1.16 ; 1.25 -1.6:1 ; 1.5-2.0:1 ;
2.0-2.8:1 ; 2.8-4.5:1 ; 4.5-7.5:1 ; 7.5-11.5:1
Optical lens shift Vertical between -100% to +130%, depending on lens
Horizontal up to +/- 40%, depending on lens
Motorized zoom and focus (with lens memory on TLD lenses)
Motorized lens shift (with position memory on all lenses)
Color correction P7
Light source laser phosphor with inorganic phosphor wheel
Light source lifetime 25,000 hrs
Optical dowser Digital
Picture-by-picture Two sources simultaneously
Sealed DLP™ core Standard
Orientation 360°
DMX 512 Standard
WARP Direct adjust OSD + toolset
Image processing Embedded warp & blend
Keystone correction Yes
Integrated web server Yes
CLO (constant light output) Standard
3D Active eye wear (optional), passive circular (optional); 2 flash up to 200Hz*
Inputs Single HDBaseT; HDMI2.0 (HDCP2.2, HDR10); DP 1.2 (HDCP 1.3); Quad
3G/12G SDI / BarcoLink ULTRA
Optional Inputs Quad DP1.2 / Fiber SFP
Input resolutions From NTSC up to 4K (4,096 x 2,160)
refresh rates:
24hz to 120hz 4K/4KUHD (4096 x 2160/ 3860 x 2400) to 240hz WQXGA
(2560 x 1600)
Max. pixel clock 600 MHz
