197R5906112 /15 UDX
Passive
stereo
2 column mode (2x1
layout)
1920 x 2160 @60 Hz
Native video timings
• UDX-U-series: 1600 x 1200 @60 Hz
• UDX-W-series: 1920 x 1200 @60 Hz
• UDX-4k-series: 3840 x 2400 @60 Hz
CAUTION: In order to display high resolution images (e.g.: 3840 x 2160 @60 Hz) via the DP1.2
input, the quality of the cable must be adequate, in addition the length of the cable can also
influence the performance. In case there is an issue with one of these criteria the automatic link-
training initiated by the DP-standard may decide to switch to a lower resolution.
A.16 Specifications SFP inputs
For readability, the video timings listed are summarized. For the full list of video timings, refer to the
appendices.
SFP specifications
Color space YCbCr
Color depth 10 bpc
Chroma sampling 4:2:2
Audio support not supported
Video timings
progressive
11
Type Port type Format
HD-SDI Single link
• Up to 1920 x 1080 @24 Hz
• Up to 1920 x 1080 @25 Hz
• Up to 1920 x 1080 @30 Hz
• Up to 1280 x 720 @50 Hz
• Up to 1280 x 720 @60 Hz
• Up to 1280 x 720 @24 Hz
• Up to 1280 x 720 @30 Hz
• Up to 1280 x 720 @25 Hz
3G-SDI Single link 1920 x 1080 @50 Hz and @60 Hz
1920 x 1200 @50 Hz, @59.94 Hz and
@60 Hz.
2048 x 1080 @50 Hz and @60 Hz
12G-SDI Single link 3840 x 2160 @50 Hz and @60 Hz
4096 x 2160 @50 Hz and @60 Hz
3840 x 2400 @50 Hz, @59.94 and @60
Hz
Specifications
11. For the full list of video timings, see Appendix
