R5906112 /15 UDX194
Specification
Value
12G-SDI
“BarcoLink 4k”
(Channel A only)
Single link 3840 x 2400 @50 Hz, @59.94 Hz and
@60 Hz.
A.13 Specifications HDMI inputs
For readability, the video timings listed are summarized. For the full list of video timings, refer to the
appendices.
HDMI specifications
Specification
Value
Pixel rate 25 – 600 MHz pixel clock
HDCP support
• HDCP 1.x
• HDCP 2.2
• RGB 4:4:4
Color space
• YCbCr 4:2:0
• YCbCr 4:2:2
• YCbCr 4:4:4
• RGB 4:4:4
Color depth
• 24 bpp
• 30 bpp
• 36 bpp
3D support
• Field sequential 3D (Active 3D)
- Frame-packed
- Top Bottom progressive
- Side-by-side progressive
• Passive 3D not supported.
For future release
• Interlaced support
Audio Not supported
Video timings
7
• Up to 4096 x 2160 @24 Hz
• Up to 4096 x 2160 @25 Hz
• Up to 4096 x 2160 @30 Hz
• Up to 2048 x 1080 @48 Hz
• Up to 4096 x 2160 @50 Hz
• Up to 4096 x 2160 @60 Hz
Native video timings
• UDX-U-series: 1600 x 1200 @60 Hz
• UDX-W-series: 1920 x 1200 @60 Hz
• UDX-4k-series: 3840 x 2400 @60 Hz
A.14 Specifications HDBaseT inputs
For readability, the video timings listed are summarized. For the full list of video timings, refer to the
appendices.
Specifications
