R5906112 /15 UDX182
Noise level (typical at 25°C/
77°F)
49 dB(A)
Operational ambient
temperature
0°-40°C/ 32°-104°F (45°C reduced power)
Operational humidity 0-80% (non condens)
Dissipation BTU Max. 6,600 BTU/h
Dimensions (WxLxH) 660 x 830 x 350 mm (25.98 x 32.67 x 13.77")
Shipping Dimensions (WxLxH) 980 x 1,200 x 760 mm (38.58 x 47.24 x 29.92")
Weight 87.5 kg (193 lbs)/shipping weight from factory: 105 kg (231 lbs)
Standard accessories Power cord, wireless/XLR wired rugged remote control
Certifications Compliant with UL60950-1 and EN60950-1, complies with FCC rules &
regulations, part 15 Class A and CE EN55032 Class A, Rohs
Warranty 3 years
* Software upgradeable. Check with your local authorized Barco sales
representative for full details.
A.5 Specifications of the UDX-W40
Specifications
Projector type WUXGA 3-chip DLP digital projector
Resolution 1920 x 1200
Technology 0.96" DMD™ x3
Brightness 40,000 center lumen/ 39,000 ansi lumen / 43,000 ISO
Contrast ratio Full field 2200:1 / Barco Dyna Black 20000:1
Brightness uniformity 95%
Aspect ratio 16:10
ScenergiX Horizontal and vertical edge blending
Lenses TLD+ 0.37, 0.65-0.85, 0.8-1.16:1 ; 1.25-1.6:1 ; 1.5-2.0:1 ; 2.0-2.8:1 ; 2.8-
4.5:1 ; 4.5-7.5:1 ; 7.5-11.5:1
Optical lens shift Vertical between -100% to +130%, depending on lens
Horizontal up to +/- 40%, depending on lens
Motorized zoom and focus (with lens memory on TLD lenses)
Motorized lens shift (with position memory on all lenses)
Color correction P7
Light source laser phosphor with inorganic phosphor wheel
Light source lifetime 20,000 hrs
Optical dowser Digital
Picture-by-picture Two sources simultaneously
Orientation 360°
Specifications
