193R5906112 /15 UDX
Dissipation BTU Max. 9,895 BTU/h
Dimensions (WxLxH) 660 x 830 x 350 mm / 25.98 x 32.7 x 13.78 inches
Shipping Dimensions (WxLxH) 800 x 1,200 x 685 mm / 31.49 x 47.24 x 26.96 inches
Weight 92 kg (202 lbs)/shipping weight from factory: 110 kg (242 lbs)
Standard accessories Power cord, wireless/XLR wired rugged remote control, bottom rigging kit/
clamps
Certifications Compliant with UL60950-1 and EN60950-1, complies with FCC rules &
regulations, part 15 Class A and CE EN55032 Class A, Rohs
Warranty 3 years
A.12 Specifications SDI inputs
For readability, the video timings listed are summarized. For the full list of video timings, refer to the
appendices.
HD-SDI follows the SMPTE 292M standard.
3G SDI follows the SMPTE 425M standard Level A.
12G-SDI
6
follows the SMPTE ST-2082-1 and ST-2082-10 standards.
SDI specifications
Specification
Value
Color space YCbCr
Color depth 10 bpc
Chroma sampling 4:2:2
Audio not supported
For future release
• 3D support
• Interlaced support
• Segmented frame support
Video timings
progressive
7
Type Port type Format
HD-SDI Single link
Quad link
• Up to 1920 x 1080 @24 Hz
• Up to 1920 x 1080 @25 Hz
• Up to 1920 x 1080 @30 Hz
• Up to 1280 x 720 @50 Hz
• Up to 1280 x 720 @60 Hz
3G-SDI Level A
8
Single link
Quad link
Up to 2048 x 1080 @50 Hz
Up to 2048 x 1080 @60 Hz
3G-SDI
“BarcoLink”
Single link
Quad link
1920 x 1200 @50 Hz, @59.94 Hz and
@60 Hz
12G-SDI (Channel
A only)
Single link 3840 x 2160 @50 Hz and @60 Hz
4096 x 2160 @50 Hz and @60 Hz
Specifications
6. Quad Combo Input Mk II only.
7. For the full list of video timings, see Appendix user guide
8. Quad Combo Input Mk I only.
