R5906112 /15 UDX36

3.7 Pulse RCU, function of the “RGB filter” button

Filtering the color of the projected image

By pressing the RGB filter button on the RCU you can place a color filter on the output of the projector. This

feature can be useful during the installation and configuration of a multi-projector or multi-channel setup. By

having one projector project a red image and another project a green image, it is easier to spot and adjust the

overlap section.

By pressing this button multiple times, you will have different active filters, in the following cycle:

• Red + Green + Blue (default)

• Red only

• Green only

• Blue only

• Red + Green

• Green + Blue

• Red + Blue

• Red + Green + Blue

• etc

After powering up, the colors will always revert back to full RGB.

3.8 Displaying and Programming addresses into

the RCU

Displaying the Projector Address on the Screen.

1. If the projector is on, press the menu key and navigate to the Status page. The projector address and the

broadcast address can be seen under the Communication heading.

The projector's address is displayed on the LCD status screen and / or the OSD.

How to Program an Address into the RCU?

1. Press the Address button until the Button pressed indicator lights up continuously (proximately 5

seconds).

2. Enter the address with the digit buttons within the time the indicator lights up (also proximately 5 seconds).

Note: That address can be any value between 0 and 31.

Tip: A few examples:

To enter address 3, press "3" digit button on the RCU to set the RCU's address to 3 and wait until

the button pressed indicator is out. Alternatively, you can also press “0” and “3”. This way, the

button pressed indicator goes out immediately.

To enter address 31, then press “3” and “1” on the digit button on the RCU and the button pressed

indicator goes out immediately.

3.9 Using the XLR connector of the RCU

Connecting a cable with the XLR connector will reset the broadcast address of the RCU to its

default value '0'.
