3.16.6 Electrical curcuit diagram of section distributor EHS control.
Electrical curcuit diagram of section distributor EHS control of tractors BELARUS-
3522-5 (modifications with electronic joystick unit BOCORO and with electronic joystick
unit EJU-1) is shown in figure 3.16.17.
The components list of electrical circuit diagram of section distributor EHS control,
shown in figure 3.16.17, is given in table 3.3.
Table 3.3.
Pos.
indication
Name Q-
ty
Note
Connectors of the company “Deutz”
XS2.1,XS2.2 Female reeptacle DT06-2SA 2
XS12.1,XS12.2 Female reeptacle DT06-12SA 2
Connectors of the company AMP catalogue
889759
XS2.3 Female receptacle 0-0282189-1 1
XS4.1... XS4.4 Female receptacle 0-0282192-1 4
XS4.5 Female receptacle 0-0282088-1 1
XS6 Female receptacle 1-965640-1 1
Plug-and-jack of the company AMP
XP7.1...XP7.3 Plug 0-1718230-1 3
XS7.1...XS7.3 Cable receptacle 0-0967650-1 3
A Electromagnet 1 837 001 270 of drain section
R917 000 841
1
EHS1...EHS4 Distribution valve EHS-PWM R917 000b 145 4
EJ1,EJ2 Joystick 4EJSWE-10/ST 03 5 BOCORO
(08 352 076)
2
EJ3 Electronic joystick unit EJU-1
TU BY 300044189.057-2009 1
EJ3.1,EJ3.2 Joystick D-01 TU BY 300044189.057-2009 2
P Electronic unit BPO HLL TU BY
190431397.007-2006
1
