Brother PJ-722 User Manual

Web Based Management
133
12
Configuring the Printer Settings Using Web Based
Management (Web Browser) 12
A standard web browser can be used to change your print server settings using the HTTP (Hyper Text
Transfer Protocol).
a In your browser's address bar, type the IP address of your printer (or print server name).
For example: http://192.168.1.2
Note
If you have edited the hosts file on your computer or are using a Domain Name System, you can also enter
the DNS name of the print server. As the print server supports TCP/IP and NetBIOS, you can also enter
the NetBIOS name of the print server. The NetBIOS name can be seen on the printer settings page. The
NetBIOS name assigned is the first 15 characters of the node name and by default it will appear as
“BRWxxxxxxxxxxxx” where “xx xxxxxxxxxx” is the Ethernet address.
b You can now change the print server settings.
Note
Setting a password
We recommend setting a login password to prevent unauthorized access to the Web Based Management.
a Click [Administrator].
b Enter the password you want to use (up to 32 characters).
c Re-enter the password in [Confirm new password] box.
d Click [Submit].
The next time you access Web Based Management, enter a password in the [Login] box, and then
click .
After configuring the settings, logout by clicking .
You can also set a password by clicking [Please configure the password.] on the printer’s web page if
you are not setting a login password.

Brother PJ-722 Specifications

General

Print Technology	Direct Thermal
Print Speed	Up to 8 ppm
Interface	USB
Power Source	AC adapter
Dimensions	255 mm x 55 mm x 30 mm
Weight	480 g
Paper Size	A4, Letter
Media Type	Roll paper, Fanfold paper
