Canon EOS 80D User Manual

S Selecting the AF Area and AF Point N
122
You can manually select the AF point or zone.
1
Press the <S> or <B> button
( 9 ).
 The AF points will be displayed in the
viewfinder.
 In the Zone AF mode or Large Zone
AF mode, the selected zone will be
displayed.
2
Select an AF point.
 The AF point selection will change in
the direction you tilt <
9 >. If you
press <
0 >, the center AF point (or
center zone) will be selected.
 You can also select an AF point by
shifting horizontally with the <
6 >
dial or vertically with the <
5 > dial.
 In the Zone AF mode, turning the
<
6 > or < 5 > dial will change the
zone in a looping sequence.
Selecting the AF Point Manually
< 6 >
<
5 >
 When you hold down the <Q> button and turn the <6> dial, you can
select an AF point by shifting vertically.
 When [8C.Fn II-11: Initial AFpt, o AI Servo AF] is set to [1: Initial
o AF pt selected] (p.422), you can use this method to manually select
the AI Servo’s AF initial position.
 When you press the <S> or <B> button, the LCD panel displays the
following:
• Zone AF, Large Zone AF, and 45-point automatic selection AF: M AF
• 1 pt AF: SEL N (Center)/SEL AF (Off-center)

Canon EOS 80D Specifications

General

Sensor	APS-C CMOS
Megapixels	24.2 MP
ISO Range	100-16000 (expandable to 25600)
Continuous Shooting Speed	7 fps
Video Resolution	1080p at 60 fps
Screen	3.0-inch Vari-angle touchscreen LCD
Connectivity	Wi-Fi, NFC
Battery Life	Approx. 960 shots (CIPA)
Camera Type	DSLR
Lens Mount	Canon EF/EF-S
Battery	LP-E6N
Weight	730 g (body only)
Dimensions	139 x 105.2 x 78.5 mm
Storage Media	SD/SDHC/SDXC card
Autofocus Points	45 points
Viewfinder	Optical pentaprism, 100% coverage
Shutter Speed	1/8000 to 30 sec
