Canon EOS 80D User Manual

78
<A> is a fully automatic mode. The camera analyzes the scene
and sets the optimum settings automatically.
It also adjusts focus
automatically by detecting whether the subject is still or moving (p.81).
1
Set the Mode Dial to <A>.
 Turn the Mode Dial while holding
down the lock release button at the
center.
2
Aim the Area AF frame over the
subject.
 All the AF points will be used to focus,
and the camera will focus on the
closest object.
 Aiming the center of the Area AF
frame over the subject will make
focusing easier.
3
Focus on the subject.
 Press the shutter button halfway. The
lens focusing ring will rotate to focus.
 When achieving focus, the AF point
that has achieved focus will be
displayed. At the same time, the
beeper will sound and the focus
indicator <
o > in the viewfinder will
light up.
 In low light, the AF point(s) will light
up briefly in red.
 If necessary, the built-in flash will be
raised automatically.
A Fully Automatic Shooting (Scene Intelligent Auto)
Area AF frame
Focus indicator

Canon EOS 80D Specifications

General

Sensor	APS-C CMOS
Megapixels	24.2 MP
ISO Range	100-16000 (expandable to 25600)
Continuous Shooting Speed	7 fps
Video Resolution	1080p at 60 fps
Screen	3.0-inch Vari-angle touchscreen LCD
Connectivity	Wi-Fi, NFC
Battery Life	Approx. 960 shots (CIPA)
Camera Type	DSLR
Lens Mount	Canon EF/EF-S
Battery	LP-E6N
Weight	730 g (body only)
Dimensions	139 x 105.2 x 78.5 mm
Storage Media	SD/SDHC/SDXC card
Autofocus Points	45 points
Viewfinder	Optical pentaprism, 100% coverage
Shutter Speed	1/8000 to 30 sec
