Canon EOS 80D User Manual

33
1
Getting Started
This chapter explains preparatory steps before you start
shooting and basic camera operations.
Attaching the Strap
Pass the end of the strap through
the camera’s strap mount eyelet
from the bottom. Then pass it
through the strap’s buckle as shown
in the illustration. Pull the strap to
take up any slack and make sure
the strap will not loosen from the
buckle.
The eyepiece cover is attached to
the strap (p.220).
Eyepiece cover

Canon EOS 80D Specifications

General

Sensor	APS-C CMOS
Megapixels	24.2 MP
ISO Range	100-16000 (expandable to 25600)
Continuous Shooting Speed	7 fps
Video Resolution	1080p at 60 fps
Screen	3.0-inch Vari-angle touchscreen LCD
Connectivity	Wi-Fi, NFC
Battery Life	Approx. 960 shots (CIPA)
Camera Type	DSLR
Lens Mount	Canon EF/EF-S
Battery	LP-E6N
Weight	730 g (body only)
Dimensions	139 x 105.2 x 78.5 mm
Storage Media	SD/SDHC/SDXC card
Autofocus Points	45 points
Viewfinder	Optical pentaprism, 100% coverage
Shutter Speed	1/8000 to 30 sec
