427
Fine adjustment of the AF’s point of focus is possible for viewfinder
shooting. This is called “AF Microadjustment”. Before making the
adjustment, read “General Cautions for AF Microadjustment” on page
432.
Set the adjustment amount manually by repeatedly making
adjustments, shooting, and checking the results until the desired result
is achieved. During AF, regardless of the lens used, the point of focus
will always be shifted by the adjustment amount.
1
Select [C.Fn II: Autofocus].
Under the [
8
] tab, select [
C.Fn II:
Autofocus
], then press <
0
>.
2
Select [16: AF Microadjustment].
3
Select [1: All by same amount].
4
Press the <Q> button.
The [
1: All by same amount
] screen
will appear.
8
: Fine Adjustment of AF’s Point of Focus
1: Adjust All by Same Amount
Normally, this adjustment is not required. Perform this adjustment
only if necessary. Note that performing this adjustment may prevent
accurate focusing from being achieved.
To Next Page
