Canon EOS 80D User Manual

405
Normally, the Self Cleaning Sensor Unit will eliminate most of the dust
that may be visible on captured images. However, in case visible dust
still remains, you can append the Dust Delete Data to the image for
erasing the dust spots later. The Dust Delete Data is used by Digital
Photo Professional (EOS software, p.512) to erase the dust spots
automatically.
 Prepare a solid white object such as a sheet of paper.
 Set the lens focal length to 50 mm or longer.
 Set the lens’s focus mode switch to < MF > and set the focus to
infinity (
u ). If the lens has no distance scale, rotate the camera to
face toward you and turn the focusing ring clockwise all the way.
1
Select [Dust Delete Data].
 Under the [ z 3 ] tab, select [ Dust
Delete Data
], then press < 0 >.
2
Select [OK].
 After the automatic self-cleaning of
the sensor is performed, a message
will appear. Although there will be a
shutter release sound, during the
cleaning, no picture is taken.
3 Appending Dust Delete Data N
Preparation
Obtaining the Dust Delete Data

Canon EOS 80D Specifications

General

Sensor	APS-C CMOS
Megapixels	24.2 MP
ISO Range	100-16000 (expandable to 25600)
Continuous Shooting Speed	7 fps
Video Resolution	1080p at 60 fps
Screen	3.0-inch Vari-angle touchscreen LCD
Connectivity	Wi-Fi, NFC
Battery Life	Approx. 960 shots (CIPA)
Camera Type	DSLR
Lens Mount	Canon EF/EF-S
Battery	LP-E6N
Weight	730 g (body only)
Dimensions	139 x 105.2 x 78.5 mm
Storage Media	SD/SDHC/SDXC card
Autofocus Points	45 points
Viewfinder	Optical pentaprism, 100% coverage
Shutter Speed	1/8000 to 30 sec
