Canon EOS 80D User Manual

71
You can display a grid in the viewfinder to help you check the camera tilt
or compose the shot.
1
Select [Viewfinder display].
 Under the [ 52 ] tab, select
[
Viewfinder display ], then press
<
0 >.
2
Select [Grid display].
3
Select [Show].
 When you exit the menu, the grid will
appear in the viewfinder.
Displaying the Grid
You can display a grid on the LCD monitor during Live View shooting and
before you start shooting a movie (p.270, 331).

Canon EOS 80D Specifications

General

Sensor	APS-C CMOS
Megapixels	24.2 MP
ISO Range	100-16000 (expandable to 25600)
Continuous Shooting Speed	7 fps
Video Resolution	1080p at 60 fps
Screen	3.0-inch Vari-angle touchscreen LCD
Connectivity	Wi-Fi, NFC
Battery Life	Approx. 960 shots (CIPA)
Camera Type	DSLR
Lens Mount	Canon EF/EF-S
Battery	LP-E6N
Weight	730 g (body only)
Dimensions	139 x 105.2 x 78.5 mm
Storage Media	SD/SDHC/SDXC card
Autofocus Points	45 points
Viewfinder	Optical pentaprism, 100% coverage
Shutter Speed	1/8000 to 30 sec
