Canon EOS 80D User Manual

Using the Eyepiece Cover
220
 Even if the drive mode is set to continuous shooting, only one shot can
be taken.
 You can also use the self-timer with mirror lockup.
 If approx. 30 sec. elapse after the mirror is locked up, it will go back down
automatically. Pressing the shutter button completely again locks up the
mirror again.
 When shooting with mirror lockup, using a tripod and Remote Switch
RS-60E3 (sold separately, p.221) is recommended.
 You can also use a remote controller (sold separately, p.221) with mirror
lockup. Setting the remote controller to a 2-sec. delay is recommended.
Using the Eyepiece Cover
When you take a picture without looking through the viewfinder, such as
when you use the self-timer, bulb exposure, or a remote switch, stray
light entering the viewfinder can cause the picture to look dark. To
prevent this, use the eyepiece cover (p.33) attached to the camera
strap.
During Live View shooting and movie shooting, attaching the eyepiece
cover is unnecessary.
1
Detach the eyecup.
 Push the bottom of the eyecup to
detach it.
2
Attach the eyepiece cover.
 Slide the eyepiece cover down into
the eyepiece groove to attach it.
 After you finish shooting, detach the
eyepiece cover and attach the
eyecup.

Canon EOS 80D Specifications

General

Sensor	APS-C CMOS
Megapixels	24.2 MP
ISO Range	100-16000 (expandable to 25600)
Continuous Shooting Speed	7 fps
Video Resolution	1080p at 60 fps
Screen	3.0-inch Vari-angle touchscreen LCD
Connectivity	Wi-Fi, NFC
Battery Life	Approx. 960 shots (CIPA)
Camera Type	DSLR
Lens Mount	Canon EF/EF-S
Battery	LP-E6N
Weight	730 g (body only)
Dimensions	139 x 105.2 x 78.5 mm
Storage Media	SD/SDHC/SDXC card
Autofocus Points	45 points
Viewfinder	Optical pentaprism, 100% coverage
Shutter Speed	1/8000 to 30 sec
