Canon EOS 80D User Manual

167
You can correct the white balance that is set. This adjustment will have
the same effect as using a commercially-available color temperature
conversion filter or color compensating filter. Each color can be
corrected to one of nine levels.
This function is for advanced users, particularly for those users who
understand the use of color temperature conversion and color
compensating filters and their effects.
1
Select [WB Shift/Bkt.].
 Under the [ z 2 ] tab, select [ WB
Shift/Bkt.
], then press < 0 >.
2
Set the white balance correction.
 Use < 9 > to move the “ ” mark to the
appropriate position.
 B is for blue, A for amber, M for
magenta, and G for green. The
image’s color balance will be adjusted
toward the color in the direction of the
move.
 On the right of the screen, “ Shift ”
indicates the direction and correction
amount, respectively.
 Pressing the < L > button will cancel
all the [
WB Shift/Bkt. ] settings.
 Press < 0 > to exit the setting and
return to the menu.
3 White Balance CorrectionN
White Balance Correction
Sample setting: A2, G1
 You can display <z> in the viewfinder when white balance correction is
set (p.425).
 One level of the blue/amber correction is equivalent to approx. 5 mireds
of a color temperature conversion filter. (Mired: Measuring unit indicating
the density of a color temperature conversion filter.)

Canon EOS 80D Specifications

General

Sensor	APS-C CMOS
Megapixels	24.2 MP
ISO Range	100-16000 (expandable to 25600)
Continuous Shooting Speed	7 fps
Video Resolution	1080p at 60 fps
Screen	3.0-inch Vari-angle touchscreen LCD
Connectivity	Wi-Fi, NFC
Battery Life	Approx. 960 shots (CIPA)
Camera Type	DSLR
Lens Mount	Canon EF/EF-S
Battery	LP-E6N
Weight	730 g (body only)
Dimensions	139 x 105.2 x 78.5 mm
Storage Media	SD/SDHC/SDXC card
Autofocus Points	45 points
Viewfinder	Optical pentaprism, 100% coverage
Shutter Speed	1/8000 to 30 sec
