Canon EOS 80D User Manual

128
Autofocusing with 45 points is possible. All the AF area selection modes
are selectable.
: Dual cross-type AF point. Subject
tracking is superior and the focusing
precision is higher than with other AF
points.
: Cross-type AF point. Subject
tracking is superior and high-
precision focusing is achieved.
Lenses and Usable AF Points
Group A
 Although the camera has 45 AF points, the number of usable AF
points and focusing patterns vary depending on the lens. The
lenses are thereby classified into eight groups from A to H.
 When using a lens in Groups E to H, fewer AF points will be usable.
 See which group each lens belongs to on pages 132-135.
Check
which group the lens in use belongs to.
 The number of available AF points varies depending on aspect ratio
settings (p. 146).
 When you press the <S> or <B> button, the AF points indicated by
the mark will blink. (The / AF points will stay lit.) Regarding
lighting up or blinking of the AF points, see page 123.
 For the latest “Lens Group Designations” information, check the Canon
website.
 Some lenses may not be available in certain countries or regions.

Canon EOS 80D Specifications

General

Sensor	APS-C CMOS
Megapixels	24.2 MP
ISO Range	100-16000 (expandable to 25600)
Continuous Shooting Speed	7 fps
Video Resolution	1080p at 60 fps
Screen	3.0-inch Vari-angle touchscreen LCD
Connectivity	Wi-Fi, NFC
Battery Life	Approx. 960 shots (CIPA)
Camera Type	DSLR
Lens Mount	Canon EF/EF-S
Battery	LP-E6N
Weight	730 g (body only)
Dimensions	139 x 105.2 x 78.5 mm
Storage Media	SD/SDHC/SDXC card
Autofocus Points	45 points
Viewfinder	Optical pentaprism, 100% coverage
Shutter Speed	1/8000 to 30 sec
