Canon EOS 80D User Manual

407
Dust that could not be removed by the automatic sensor cleaning can
be removed manually with a commercially-available blower, etc. Before
cleaning the sensor, detach the lens from the camera.
The image sensor is extremely delicate. If the sensor needs to be
cleaned directly, having it done by a Canon Service Center is
recommended.
1
Select [Sensor cleaning].
 Under the [ 5 3 ] tab, select [ Sensor
cleaning
], then press < 0 >.
2
Select [Clean manually].
3
Select [OK].
 In a moment, the reflex mirror will
lockup and the shutter will open.
 “ CLn ” will blink on the LCD panel.
4
Clean the sensor.
5
End the cleaning.
 Set the power switch to < 2 >.
3 Manual Sensor Cleaning N
 If you use a battery, make sure it is fully charged.
 If you use Battery Grip BG-E14 (sold separately) with AA/R6 batteries,
manual sensor cleaning will not be possible.
For the power source, using DC Coupler DR-E6 (sold separately) and AC
Adapter AC-E6N (sold separately) is recommended.

Canon EOS 80D Specifications

General

Sensor	APS-C CMOS
Megapixels	24.2 MP
ISO Range	100-16000 (expandable to 25600)
Continuous Shooting Speed	7 fps
Video Resolution	1080p at 60 fps
Screen	3.0-inch Vari-angle touchscreen LCD
Connectivity	Wi-Fi, NFC
Battery Life	Approx. 960 shots (CIPA)
Camera Type	DSLR
Lens Mount	Canon EF/EF-S
Battery	LP-E6N
Weight	730 g (body only)
Dimensions	139 x 105.2 x 78.5 mm
Storage Media	SD/SDHC/SDXC card
Autofocus Points	45 points
Viewfinder	Optical pentaprism, 100% coverage
Shutter Speed	1/8000 to 30 sec
