Canon EOS 80D User Manual

386
You can adjust the brightness of the LCD monitor to make it easier to
view.
1
Select [LCD brightness].
 Under the [ 5 2 ] tab, select [ LCD
brightness
], then press < 0 >.
2
Adjust the brightness.
 While referring to the gray chart,
press the <
Y > < Z > keys, then press
<
0 >.
Changing Image Playback Settings
3 Adjusting the LCD Monitor Brightness
To check the image’s exposure, referring to the histogram is recommended
(p.352).

Canon EOS 80D Specifications

General

Sensor	APS-C CMOS
Megapixels	24.2 MP
ISO Range	100-16000 (expandable to 25600)
Continuous Shooting Speed	7 fps
Video Resolution	1080p at 60 fps
Screen	3.0-inch Vari-angle touchscreen LCD
Connectivity	Wi-Fi, NFC
Battery Life	Approx. 960 shots (CIPA)
Camera Type	DSLR
Lens Mount	Canon EF/EF-S
Battery	LP-E6N
Weight	730 g (body only)
Dimensions	139 x 105.2 x 78.5 mm
Storage Media	SD/SDHC/SDXC card
Autofocus Points	45 points
Viewfinder	Optical pentaprism, 100% coverage
Shutter Speed	1/8000 to 30 sec
