Canon EOS 80D User Manual

36
Load a fully-charged Battery Pack LP-E6N (or LP-E6) into the camera.
The camera’s viewfinder becomes bright when a battery is
installed, and darkens when the battery is removed. If the battery
is not installed, the picture in the viewfinder becomes blurred and
focus cannot be achieved.
1
Open the cover.
 Slide the lever as shown by the
arrows and open the cover.
2
Insert the battery.
 Insert the end with the electrical
contacts.
 Insert the battery until it locks in
place.
3
Close the cover.
 Press the cover until it snaps shut.
Open the cover and remove the
battery.
 Press the battery lock lever as shown
by the arrow and remove the battery.

To prevent short circuiting of the electrical
contacts, be sure to attach the provided
protective cover (p.34) to the battery.
Installing and Removing the Battery
Installing the Battery
Removing the Battery
Only Battery Pack LP-E6N/LP-E6 can be used.

Canon EOS 80D Specifications

General

Sensor	APS-C CMOS
Megapixels	24.2 MP
ISO Range	100-16000 (expandable to 25600)
Continuous Shooting Speed	7 fps
Video Resolution	1080p at 60 fps
Screen	3.0-inch Vari-angle touchscreen LCD
Connectivity	Wi-Fi, NFC
Battery Life	Approx. 960 shots (CIPA)
Camera Type	DSLR
Lens Mount	Canon EF/EF-S
Battery	LP-E6N
Weight	730 g (body only)
Dimensions	139 x 105.2 x 78.5 mm
Storage Media	SD/SDHC/SDXC card
Autofocus Points	45 points
Viewfinder	Optical pentaprism, 100% coverage
Shutter Speed	1/8000 to 30 sec
