Customizing Functions and Onscreen Displays
104
Customizing Functions and Onscreen Displays
Customize the camcorder to match your shooting style and needs. Use the [J Other Functions] [Custom
Function] setting to adjust how some of the camcorder’s controls and functions operate in mode.
Similarly, use the [M LCD/VF Setup] [Custom Display] setting to customize the onscreen displays that
appear during recording. You can save these preferences along with other menu settings to an SD card and use
them again later (0 106).
Customizing Functions
The following table describes which functions can be customized using
[Custom Function]. For more details, refer to [Custom Function] (0 151).
1 Open the [Custom Function] submenu.
[J Other Functions] [Custom Function]
2 Select the desired function.
3 Change the setting option and then press SET.
Operating modes:
[J Other Functions]
[Custom Function]
Customizable Functions with [Custom Function]
Menu item Description
[Shockless Gain] Determines the speed of the transition when the gain is changed.
[Shockless WB] Creates a softer transition when the white balance is changed.
[AE Response] Controls the camcorder’s response when you change the automatic exposure setting.
[Iris Limit] Sets a maximum aperture value (F8.0) to be used for shooting.
[I. Ring Direction] Changes the direction of the adjustment when turning the manual ring while it is set to IRIS(ND).
[F. Ring Direction] Changes the direction of the adjustment when turning the manual ring while it is set to FOCUS.
[Z. Ring Direction] Changes the direction of the adjustment when turning the manual ring while it is set to ZOOM.
[F. Ring Control] Selects the sensitivity of the response when operating the manual ring while it is set to FOCUS.
[Z. Ring Control] Selects the sensitivity of the response when operating the manual ring while it is set to ZOOM.
[F. Assist B&W]
Automatically switches the screen to B&W while the focus assist functions (peaking and magnification) are
activated. You can have the screen switch to B&W when only the peaking is activated, when only the
magnification is activated or when both are activated. Focus assist functions will not appear on an external
monitor.
[Obj. Dist. Unit]
Selects the units of distance (meters or feet) displayed when the camcorder shows the distance to the
subject in manual focus mode.
[Zoom Indicator] Selects the display of the zoom indicator between a graphic bar and a numeric display (0 to 99).
[ZR-2000 AE SHIFT]
Selects the function of the AE SHIFT dial on the optional ZR-2000 Zoom Remote Controller between adjusting
either the exposure compensation or the aperture value.
[Scan Reverse Rec] Inverts the recorded image horizontally, vertically or horizontally and vertically.
[Character Rec]
When this function is set to [On], all of the onscreen displays will be recorded to the clip exactly as they
appear on the screen.
COPY

Canon XF105 Specifications

General

Sensor type	CMOS
Total megapixels	2.37 MP
Optical sensor size	1/1.3 \
Effective megapixels (image)	2.07 MP
Filter size	58 mm
Digital zoom	- x
Optical zoom	10 x
Image stabilizer	Yes
Focal length range	4.25 - 42.5 mm
Interchangeable lens	-
Image stabilizer type	Optical Image Stabilization (OIS)
Minimum aperture number	1.8
Focal length (35mm film equivalent)	30.4 - 304 mm
Memory slots	2
Camcorder media type	Memory card
Disc types supported	No
Compatible memory cards	CF, SD
Maximum memory card size	128 GB
Internal storage capacity	- GB
Focus adjustment	Auto/Manual
Closest focusing distance	0.02 m
Camera shutter speed	0.0005 s
Display diagonal	3.5 \
Display resolution (numeric)	920000 pixels
Viewfinder type	Electronic
Viewfinder screen size	0.24 \
Camcorder type	Handheld camcorder
Image processor	DIGIC DV III
Minimum illumination	4.5 lx
Product color	Black
Video resolutions	1280 x 720, 1440 x 1080, 1920 x 1080 pixels
Maximum frame rate	60 fps
Video formats supported	MXF
Maximum video resolution	1920 x 1080 pixels
Maximum image resolution	- pixels
PCM digital audio	16-bit/48 kHz
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) out	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Battery voltage	7.4 V
Battery capacity	- mAh
Battery life (max)	- h
Video recording time	10.4 h
Operating temperature (T-T)	0 - 40 °C
Cables included	Component
Memory card included	CF
Video compression formats	MPEG2

Weight and Dimensions

Depth	250 mm
Width	121 mm
Height	148 mm
Weight	1290 g
