Preparing the Camcorder
Using the Wireless Controller to Operate the Camcorder
When using the wireless controller, point it at the camcorder’s remote
sensor. When the wireless controller's buttons are operated, the
camcorder's tally lamps will illuminate.
NOTES
• When you use the START/STOP button or ZOOM buttons on the wireless
controller, you must press the record enable button simultaneously with
the desired button.
• When the camcorder cannot be operated with the wireless controller, or when it can only be operated at very
close range, replace the battery.
• The wireless controller may not work properly when the remote sensor is located under strong light sources or
direct sunlight.
Using a Tripod
You can mount the camcorder on a tripod but do not use tripods with
mounting screws longer than 5.5 mm as this may cause damage to the
camcorder.
Using a Tripod with 0.95 cm (3/8") Mounting Screws
To use a tripod with 0.95 cm (3/8") mounting screws, first attach the
optional TB-1 Tripod Adapter Base to the camcorder and then attach the
tripod to the adapter base.
1 Remove the tripod base from the camcorder.
• Remove the 4 screws and then remove the base.
2 Attach the optional TB-1 Tripod Adapter Base.
• Firmly screw in the 4 screws.
3 Attach the tripod.
• Firmly screw in the tripod screw.
• If a tripod has both a 0.64 cm (1/4") screw and 0.95 cm (3/8")
mounting screw, firmly screw in both.
COPY

Canon XF105 Specifications

General

Sensor type	CMOS
Total megapixels	2.37 MP
Optical sensor size	1/1.3 \
Effective megapixels (image)	2.07 MP
Filter size	58 mm
Digital zoom	- x
Optical zoom	10 x
Image stabilizer	Yes
Focal length range	4.25 - 42.5 mm
Interchangeable lens	-
Image stabilizer type	Optical Image Stabilization (OIS)
Minimum aperture number	1.8
Focal length (35mm film equivalent)	30.4 - 304 mm
Memory slots	2
Camcorder media type	Memory card
Disc types supported	No
Compatible memory cards	CF, SD
Maximum memory card size	128 GB
Internal storage capacity	- GB
Focus adjustment	Auto/Manual
Closest focusing distance	0.02 m
Camera shutter speed	0.0005 s
Display diagonal	3.5 \
Display resolution (numeric)	920000 pixels
Viewfinder type	Electronic
Viewfinder screen size	0.24 \
Camcorder type	Handheld camcorder
Image processor	DIGIC DV III
Minimum illumination	4.5 lx
Product color	Black
Video resolutions	1280 x 720, 1440 x 1080, 1920 x 1080 pixels
Maximum frame rate	60 fps
Video formats supported	MXF
Maximum video resolution	1920 x 1080 pixels
Maximum image resolution	- pixels
PCM digital audio	16-bit/48 kHz
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) out	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Battery voltage	7.4 V
Battery capacity	- mAh
Battery life (max)	- h
Video recording time	10.4 h
Operating temperature (T-T)	0 - 40 °C
Cables included	Component
Memory card included	CF
Video compression formats	MPEG2

Weight and Dimensions

Depth	250 mm
Width	121 mm
Height	148 mm
Weight	1290 g
