37
Preparing Recording Media
4 Select [OK] and then press SET.
• If you are using the [Complete] initialization option, press SET to cancel the operation while it is in progress.
You can use the SD card but all data will be erased.
5 When the confirmation message appears, press SET.
• The SD card is initialized and all the data it contains is erased.
IMPORTANT
• Initializing the recording media will permanently erase all data, including clips with an e mark, protected
photos, and custom picture information. Lost data cannot be recovered. Make sure you save important
recordings in advance.
• Depending on the SD card, the complete initialization may take up to a few minutes.
NOTES
• While recording on a CF card, you can initialize another CF card in the other CF card slot.
Switching Between the CF Card Slots
The camcorder features two CF card slots, CF card slot A (CFj) and CF
card slot B (CFl). If both slots contain a CF card, you can switch between
them as necessary.
Press the SLOT SELECT button.
• The access indicator of the selected CF card slot will illuminate in green.
NOTES
• If both CF card slots contain a CF card and you open the cover of the
selected slot, the camcorder will automatically switch to the other slot.
• You cannot use the SLOT SELECT button to switch between CF card
slots while recording.
Selecting the CF Card Recording Method
The camcorder features two useful CF card recording methods, relay recording and double slot recording.
Relay recording: This allows you to continue recording on another CF card without interruption if the CF card you
are using becomes full. Relay recording is available from CF card slot A to CF card slot B, and vice versa.
Double slot recording: This records the same clip simultaneously to both CF cards, which is a convenient way to
make a backup copy of your recording while you record.
Operating modes:
Operating modes:
COPY

Canon XF105 Specifications

General

Sensor type	CMOS
Total megapixels	2.37 MP
Optical sensor size	1/1.3 \
Effective megapixels (image)	2.07 MP
Filter size	58 mm
Digital zoom	- x
Optical zoom	10 x
Image stabilizer	Yes
Focal length range	4.25 - 42.5 mm
Interchangeable lens	-
Image stabilizer type	Optical Image Stabilization (OIS)
Minimum aperture number	1.8
Focal length (35mm film equivalent)	30.4 - 304 mm
Memory slots	2
Camcorder media type	Memory card
Disc types supported	No
Compatible memory cards	CF, SD
Maximum memory card size	128 GB
Internal storage capacity	- GB
Focus adjustment	Auto/Manual
Closest focusing distance	0.02 m
Camera shutter speed	0.0005 s
Display diagonal	3.5 \
Display resolution (numeric)	920000 pixels
Viewfinder type	Electronic
Viewfinder screen size	0.24 \
Camcorder type	Handheld camcorder
Image processor	DIGIC DV III
Minimum illumination	4.5 lx
Product color	Black
Video resolutions	1280 x 720, 1440 x 1080, 1920 x 1080 pixels
Maximum frame rate	60 fps
Video formats supported	MXF
Maximum video resolution	1920 x 1080 pixels
Maximum image resolution	- pixels
PCM digital audio	16-bit/48 kHz
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) out	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Battery voltage	7.4 V
Battery capacity	- mAh
Battery life (max)	- h
Video recording time	10.4 h
Operating temperature (T-T)	0 - 40 °C
Cables included	Component
Memory card included	CF
Video compression formats	MPEG2

Weight and Dimensions

Depth	250 mm
Width	121 mm
Height	148 mm
Weight	1290 g
