Video Configuration: Bit Rate, Resolution and Frame Rate
Video Configuration: Bit Rate, Resolution and Frame Rate
Before you record, select the bit rate, resolution (frame size) and frame
rate that best match your creative needs.
1 Open the [Bit Rate/Resolution] submenu to set the bit rate and
resolution.
[J Other Functions] [Bit Rate/Resolution]
2 Select the desired option and then press SET.
• The selected bit rate and resolution will appear on the right side of the
screen.
• If you selected [35 Mbps 1440x1080], [Frame Rate] will automatically
be set to [50i] so you do not need to continue with the rest of this
procedure.
3 Open the [Frame Rate] submenu to set the frame rate.
[J Other Functions] [Frame Rate]
4 Select the desired option and then press SET.
• The selected frame rate will appear on the right side of the screen.
NOTES
• For details on the signal output from each terminal, refer to Video Output Configuration (0 121).
Operating modes:
[J Other Functions]
[Bit Rate/Resolution]
[50 Mbps 1920x1080]
[J Other Functions]
[Frame Rate]
[50i]
Available bit rate, resolution and frame rate settings
* The first line indicates the bit rate (in Mbps); the second line indicates in parentheses
whether the bit rate is constant (CBR) or variable (VBR), and the color sampling.
Bit rate* Resolution
Frame rate
50i 50P 25P
50 Mbps
(CBR 4:2:2)
1920 x 1080 N – N
1280 x 720 – N N
35 Mbps
(VBR 4:2:0)
1920 x 1080 N – N
1440 x 1080 N – –
1280 x 720 – N N
25 Mbps
(CBR 4:2:0)
1440 x 1080 N – N
COPY

Canon XF105 Specifications

General

Sensor type	CMOS
Total megapixels	2.37 MP
Optical sensor size	1/1.3 \
Effective megapixels (image)	2.07 MP
Filter size	58 mm
Digital zoom	- x
Optical zoom	10 x
Image stabilizer	Yes
Focal length range	4.25 - 42.5 mm
Interchangeable lens	-
Image stabilizer type	Optical Image Stabilization (OIS)
Minimum aperture number	1.8
Focal length (35mm film equivalent)	30.4 - 304 mm
Memory slots	2
Camcorder media type	Memory card
Disc types supported	No
Compatible memory cards	CF, SD
Maximum memory card size	128 GB
Internal storage capacity	- GB
Focus adjustment	Auto/Manual
Closest focusing distance	0.02 m
Camera shutter speed	0.0005 s
Display diagonal	3.5 \
Display resolution (numeric)	920000 pixels
Viewfinder type	Electronic
Viewfinder screen size	0.24 \
Camcorder type	Handheld camcorder
Image processor	DIGIC DV III
Minimum illumination	4.5 lx
Product color	Black
Video resolutions	1280 x 720, 1440 x 1080, 1920 x 1080 pixels
Maximum frame rate	60 fps
Video formats supported	MXF
Maximum video resolution	1920 x 1080 pixels
Maximum image resolution	- pixels
PCM digital audio	16-bit/48 kHz
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) out	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Battery voltage	7.4 V
Battery capacity	- mAh
Battery life (max)	- h
Video recording time	10.4 h
Operating temperature (T-T)	0 - 40 °C
Cables included	Component
Memory card included	CF
Video compression formats	MPEG2

Weight and Dimensions

Depth	250 mm
Width	121 mm
Height	148 mm
Weight	1290 g
