Saving and Loading Camera Settings
106
Saving and Loading Camera Settings
After you adjust settings in the menus, you can save those settings on an SD card. You can load those settings
at a later date or on another XF105 or XF100 camcorder so that you can use that camcorder in the same exact
way.
Saving Camera Settings to an SD Card
1 Open the [Save To b] submenu.
[J Other Functions] [Transfer Menu] [Save To b]
2 Select [OK] and press SET.
• The current settings are saved to the SD card. If the SD card already
has camera settings on it, they will be overwritten.
3 When the confirmation screen appears, press SET.
Loading Camera Settings from an SD Card
Make sure an SD card with camera settings to be loaded is inserted in the
camcorder.
1 Open the [Load From b] submenu.
[J Other Functions] [Transfer Menu] [Load From b]
2 Select [OK] and press SET.
• After the camcorder’s current settings are replaced with the settings
saved on the SD card, the screen will turn black momentarily and the camcorder will restart.
NOTES
• The SD card includes a text file that lists the camera settings. You can check the settings by using a USB card
reader to access the SD card on a computer. In the [CAMSET] folder, open the file “CAMSET2.TXT”.
• The camera settings can be used with other XF105 and XF100 camcorders. However, camera settings from
Canon XF305 and XF300 camcorders cannot be used with this camcorder.
• When loading camera settings from an SD card, even protected custom picture settings in the camcorder will
be replaced.
Operating modes:
[J Other Functions]
[Transfer Menu]
[Save To b]
[J Other Functions]
[Transfer Menu]
[Load From b]
COPY

Canon XF105 Specifications

General

Sensor type	CMOS
Total megapixels	2.37 MP
Optical sensor size	1/1.3 \
Effective megapixels (image)	2.07 MP
Filter size	58 mm
Digital zoom	- x
Optical zoom	10 x
Image stabilizer	Yes
Focal length range	4.25 - 42.5 mm
Interchangeable lens	-
Image stabilizer type	Optical Image Stabilization (OIS)
Minimum aperture number	1.8
Focal length (35mm film equivalent)	30.4 - 304 mm
Memory slots	2
Camcorder media type	Memory card
Disc types supported	No
Compatible memory cards	CF, SD
Maximum memory card size	128 GB
Internal storage capacity	- GB
Focus adjustment	Auto/Manual
Closest focusing distance	0.02 m
Camera shutter speed	0.0005 s
Display diagonal	3.5 \
Display resolution (numeric)	920000 pixels
Viewfinder type	Electronic
Viewfinder screen size	0.24 \
Camcorder type	Handheld camcorder
Image processor	DIGIC DV III
Minimum illumination	4.5 lx
Product color	Black
Video resolutions	1280 x 720, 1440 x 1080, 1920 x 1080 pixels
Maximum frame rate	60 fps
Video formats supported	MXF
Maximum video resolution	1920 x 1080 pixels
Maximum image resolution	- pixels
PCM digital audio	16-bit/48 kHz
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) out	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Battery voltage	7.4 V
Battery capacity	- mAh
Battery life (max)	- h
Video recording time	10.4 h
Operating temperature (T-T)	0 - 40 °C
Cables included	Component
Memory card included	CF
Video compression formats	MPEG2

Weight and Dimensions

Depth	250 mm
Width	121 mm
Height	148 mm
Weight	1290 g
