Image Stabilizer
52
Image Stabilizer
Use the image stabilizer to compensate for camcorder shake in order to
achieve steadier shots. There are 3 methods of image stabilization; select
the method that best suits your needs.
Dynamic IS P: Dynamic IS compensates for a higher degree of
camcorder shake, such as when shooting while walking, and is more
effective as the zoom approaches full wide angle.
Standard IS O: Standard IS compensates for a lower degree of
camcorder shake, such as when shooting while remaining stationary, and is suitable for shooting natural-looking
scenes.
Powered IS Q: Powered IS is most effective when you are stationary and zooming in on far subjects using high
zoom ratios (the more you approach the telephoto end). This mode is not suitable for tilting and panning shots.
Dynamic IS and Standard IS are activated using the camera menu. Powered IS is activated using an assignable
button.
To activate Dynamic IS or Standard IS
1 Open the [OIS Functions] submenu.
[l Camera Setup] [OIS Functions]
2 Select [Img Stab.] and then press SET.
• Select [Off] to turn off image stabilization.
3 Open the [Image Stabilizer] submenu.
[l Camera Setup] [Image Stabilizer]
4 Select [Dynamic] or [Standard] and then press SET.
• The icon of the selected mode appears on the bottom of the screen.
To activate Powered IS
By default, assignable button 1 is set to [Powered IS]. Press the button to
activate Powered IS. The Powered IS icon (Q) appears on the bottom of
the screen.
NOTES
• If you set an assignable button to [Img Stab.] (0 94), you can press the
button to turn the selected image stabilization method on or off.
• If the degree of camcorder shake is too high, the image stabilizer may
not be able to fully compensate.
• When you are using [Dynamic] mode, the edges of the picture may be
adversely affected (such as ghosting, artifacts and dark areas) when
compensating for a high degree of camcorder shake.
• When the camcorder is mounted on a tripod, turn off image stabilization.
• You can activate Powered IS even when image stabilization is turned off.
Operating modes:
[l Camera Setup]
[OIS Functions]
[Img Stab.]
COPY

Canon XF105 Specifications

General

Sensor type	CMOS
Total megapixels	2.37 MP
Optical sensor size	1/1.3 \
Effective megapixels (image)	2.07 MP
Filter size	58 mm
Digital zoom	- x
Optical zoom	10 x
Image stabilizer	Yes
Focal length range	4.25 - 42.5 mm
Interchangeable lens	-
Image stabilizer type	Optical Image Stabilization (OIS)
Minimum aperture number	1.8
Focal length (35mm film equivalent)	30.4 - 304 mm
Memory slots	2
Camcorder media type	Memory card
Disc types supported	No
Compatible memory cards	CF, SD
Maximum memory card size	128 GB
Internal storage capacity	- GB
Focus adjustment	Auto/Manual
Closest focusing distance	0.02 m
Camera shutter speed	0.0005 s
Display diagonal	3.5 \
Display resolution (numeric)	920000 pixels
Viewfinder type	Electronic
Viewfinder screen size	0.24 \
Camcorder type	Handheld camcorder
Image processor	DIGIC DV III
Minimum illumination	4.5 lx
Product color	Black
Video resolutions	1280 x 720, 1440 x 1080, 1920 x 1080 pixels
Maximum frame rate	60 fps
Video formats supported	MXF
Maximum video resolution	1920 x 1080 pixels
Maximum image resolution	- pixels
PCM digital audio	16-bit/48 kHz
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) out	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Battery voltage	7.4 V
Battery capacity	- mAh
Battery life (max)	- h
Video recording time	10.4 h
Operating temperature (T-T)	0 - 40 °C
Cables included	Component
Memory card included	CF
Video compression formats	MPEG2

Weight and Dimensions

Depth	250 mm
Width	121 mm
Height	148 mm
Weight	1290 g
