Setting the Time Code
70
4 Change the rest of the fields (minutes, seconds, frame) in the same way.
• Press the CANCEL button to close the screen without setting the time code.
5 Select [Set] to close the screen.
• If the running mode is set to [Free Run], the time code will start running from the value set in steps 2 to 4.
Putting the Time Code Display on Hold
If you set an assignable button to [Time Code Hold] (0 94), you can freeze the display of the time code*. While
the time code display is put on hold, [H] will appear on the screen next to the time code.
The time code continues to run normally while the time code display is on hold. When you resume the time code
display, the current time code will be displayed.
* The time code signal output from the HD/SD SDI terminal (b only) or GENLOCK/TC terminal (b only) will not be put
on hold. The time code superimposed on the video signal output from the other terminals will be put on hold.
About the Time Code Display
An icon may appear next to the time code depending on the operation. Refer to the following table.
NOTES
• The frames value in the time code runs from 0 to 24.
• When you are using interval recording, frame recording or slow & fast motion recording mode, you cannot
select the [Free Run] option for the [Preset] running mode. Conversely, when you are using pre-recording
mode, [Free Run] is automatically set and cannot be changed.
• As long as the built-in rechargeable lithium battery is charged and you selected the [Free Run] option, the time
code continues to run even if you disconnect all other power sources. However, this is less accurate than
when the camcorder is on.
• If you set an assignable button to [Time Code] (0 94), you can press the button to open the [L TC/UB
Setup] [Time Code] submenu.
Icon Description
R The running mode is set to [Regen.].
P The running mode is set to [Preset] with the [Rec Run] option selected.
F The running mode is set to [Preset] with the [Free Run] option selected.
E Time code signal is coming from an external source.
H Time code display is on hold.
No icon Time code during clip playback.
COPY

Canon XF105 Specifications

General

Sensor type	CMOS
Total megapixels	2.37 MP
Optical sensor size	1/1.3 \
Effective megapixels (image)	2.07 MP
Filter size	58 mm
Digital zoom	- x
Optical zoom	10 x
Image stabilizer	Yes
Focal length range	4.25 - 42.5 mm
Interchangeable lens	-
Image stabilizer type	Optical Image Stabilization (OIS)
Minimum aperture number	1.8
Focal length (35mm film equivalent)	30.4 - 304 mm
Memory slots	2
Camcorder media type	Memory card
Disc types supported	No
Compatible memory cards	CF, SD
Maximum memory card size	128 GB
Internal storage capacity	- GB
Focus adjustment	Auto/Manual
Closest focusing distance	0.02 m
Camera shutter speed	0.0005 s
Display diagonal	3.5 \
Display resolution (numeric)	920000 pixels
Viewfinder type	Electronic
Viewfinder screen size	0.24 \
Camcorder type	Handheld camcorder
Image processor	DIGIC DV III
Minimum illumination	4.5 lx
Product color	Black
Video resolutions	1280 x 720, 1440 x 1080, 1920 x 1080 pixels
Maximum frame rate	60 fps
Video formats supported	MXF
Maximum video resolution	1920 x 1080 pixels
Maximum image resolution	- pixels
PCM digital audio	16-bit/48 kHz
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) out	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Battery voltage	7.4 V
Battery capacity	- mAh
Battery life (max)	- h
Video recording time	10.4 h
Operating temperature (T-T)	0 - 40 °C
Cables included	Component
Memory card included	CF
Video compression formats	MPEG2

Weight and Dimensions

Depth	250 mm
Width	121 mm
Height	148 mm
Weight	1290 g
