Canon XF105 User Manual

153
Displaying the Status Screens
Displaying the Status Screens
You can use the status screens to check the camcorder’s various recording- and playback-related settings. You
can also output the status screens on an external monitor.
1 Set an assignable button to [Status] (0 95).
2 Press the assignable button.
• The status screen most recently displayed will appear unless you turned off the camcorder or changed the
operating mode. In such case, the [Camera] status screen appears in mode and the [Buttons /
Remote] status screen appears in mode.
3 Push the joystick up/down to scroll through the status screens.
4 When you are finished, press the assignable button again to exit the status screens.
• Alternatively, you can press the MENU or CANCEL button. Pressing the MENU button will exit the status
screen and open the menu.
* Does not appear in the [Photos] index screen.
Operating modes:
Status screen Description 0
[Camera] Displays settings related to recording, such as gain, focus and
zoom.
N – 154
[Buttons/Remote] Allows you to verify the current function of each assignable button
and whether the wireless controller is on.
N N 154
[Audio]* Displays settings related to audio. N N 155
[Media] Displays information about the recording media. N N 155
[Video] Displays the settings for the video terminals and which special
recording mode is in effect.
N N 156
[User Memo] Displays the user memo that will be recorded with clips. N – 156
[Battery/Hour Meter] Allows you to check the remaining battery time, battery life and
how long the camcorder has been in operation.
N N 157
[X Data 1/3]
Displays the settings for the custom picture file that will be
embedded into clips.
N –
157
[X Data 2/3] 158
[X Data 3/3] 158
