Infrared Recording
90
Infrared Recording
This camcorder features the ability to shoot movies in dark surroundings using the camcorder's infrared light and
other sources of infrared light. Also, you can select whether the lighter areas of the picture appear in green or
white.
Activating Infrared Mode
Follow the procedure below to set the camcorder to Infrared mode and to
set the color of highlights in the picture.
1 Move the INFRARED switch to ON.
2 Open the [Monochrome] submenu to select a color.
[l Camera Setup] [Infrared] [Monochrome]
3 Select [White] or [Green] and then press SET.
NOTES
• If you set an assignable button to [IR Monochrome] (0 94), you can
press the button to activate the infrared light.
• When you activate Infrared mode, autofocus will also be activated
automatically. You can change the focus to manual focus during
Infrared mode, however.
• Depending on the light source, autofocus may not work well.
Using the Infrared Light
You can turn the infrared light on and off using an assignable button or the
CUSTOM button.
1 Open the [Light] submenu.
[l Camera Setup] [Infrared] [Light]
2 Select a desired option and then press SET.
Options
Operating modes:
[Toggle]: Allows you to turn the infrared light on and off using an assignable button or the CUSTOM button. Set an
assignable button (0 94) or CUSTOM button (0 46) to [IR Light] in advance.
[Always On]: The infrared light is always on while the camcorder is in Infrared mode.
[Always Off]: The infrared light is always off.
[l Camera Setup]
[Infrared]
[Monochrome]
[White]
[l Camera Setup]
[Infrared]
[Light]
[Toggle]
COPY

Canon XF105 Specifications

General

Sensor type	CMOS
Total megapixels	2.37 MP
Optical sensor size	1/1.3 \
Effective megapixels (image)	2.07 MP
Filter size	58 mm
Digital zoom	- x
Optical zoom	10 x
Image stabilizer	Yes
Focal length range	4.25 - 42.5 mm
Interchangeable lens	-
Image stabilizer type	Optical Image Stabilization (OIS)
Minimum aperture number	1.8
Focal length (35mm film equivalent)	30.4 - 304 mm
Memory slots	2
Camcorder media type	Memory card
Disc types supported	No
Compatible memory cards	CF, SD
Maximum memory card size	128 GB
Internal storage capacity	- GB
Focus adjustment	Auto/Manual
Closest focusing distance	0.02 m
Camera shutter speed	0.0005 s
Display diagonal	3.5 \
Display resolution (numeric)	920000 pixels
Viewfinder type	Electronic
Viewfinder screen size	0.24 \
Camcorder type	Handheld camcorder
Image processor	DIGIC DV III
Minimum illumination	4.5 lx
Product color	Black
Video resolutions	1280 x 720, 1440 x 1080, 1920 x 1080 pixels
Maximum frame rate	60 fps
Video formats supported	MXF
Maximum video resolution	1920 x 1080 pixels
Maximum image resolution	- pixels
PCM digital audio	16-bit/48 kHz
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) out	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Battery voltage	7.4 V
Battery capacity	- mAh
Battery life (max)	- h
Video recording time	10.4 h
Operating temperature (T-T)	0 - 40 °C
Cables included	Component
Memory card included	CF
Video compression formats	MPEG2

Weight and Dimensions

Depth	250 mm
Width	121 mm
Height	148 mm
Weight	1290 g
