Setting the Time Code
Setting the Time Code
The camcorder can generate a time code signal and embed it in your recordings. You can have the camcorder
output the time code signal from the HD/SD SDI terminal (b only) or GENLOCK/TC terminal
(b only; 0 73). In addition, you can superimpose the time code on video output from the HDMI OUT
terminal, HD/SD COMPONENT OUT terminal or AV terminal.
b To synchronize the camcorder’s time code to an external time code generator, refer to Synchronizing
with an External Device (0 72).
Selecting the Running Mode
You can select the running mode of the camcorder’s time code.
1 Open the time code [Mode] submenu.
[L TC/UB Setup] [Time Code] [Mode]
2 Select the desired option and then press SET.
• If you selected [Regen.], you do not need to perform the rest of this
procedure. If you selected [Preset] and would like to set the time
code’s initial value, see the following section Setting the Time Code’s
Initial Value.
3 After you select [Preset], open the time code [Run] submenu.
[L TC/UB Setup] [Time Code] [Run]
4 Select the desired option and then press SET.
Options
Setting the Time Code’s Initial Value
If you set the running mode to [Preset], you can set the initial value of the
time code.
1 Open the time code [Setting] submenu.
[L TC/UB Setup] [Time Code] [Setting]
2 Select [Set] and then press SET.
• The time code setting screen appears with an orange selection frame indicating the hours.
• To reset the time code to [00:00:00.00], select [Reset] instead.
3 Select the hours and then move (A) to minutes.
Operating modes:
[Preset]: After you select this option, select a [Run] option. With [Rec Run],
the time code runs only when recording and clips on the same CF
card will have a continuous time code; with [Free Run], the time
code runs regardless of the camcorder’s operation. You can also
choose to set the time code’s initial value for either [Run] option.
[Regen.]: The time code runs while recording. Use this running mode to
continue with the last recorded time code on the media.
[L TC/UB Setup]
[Time Code]
[Mode]
[Preset]
[L TC/UB Setup]
[Time Code]
[Run]
[Rec Run]
[L TC/UB Setup]
[Time Code]
[Setting]
COPY

Canon XF105 Specifications

General

Sensor type	CMOS
Total megapixels	2.37 MP
Optical sensor size	1/1.3 \
Effective megapixels (image)	2.07 MP
Filter size	58 mm
Digital zoom	- x
Optical zoom	10 x
Image stabilizer	Yes
Focal length range	4.25 - 42.5 mm
Interchangeable lens	-
Image stabilizer type	Optical Image Stabilization (OIS)
Minimum aperture number	1.8
Focal length (35mm film equivalent)	30.4 - 304 mm
Memory slots	2
Camcorder media type	Memory card
Disc types supported	No
Compatible memory cards	CF, SD
Maximum memory card size	128 GB
Internal storage capacity	- GB
Focus adjustment	Auto/Manual
Closest focusing distance	0.02 m
Camera shutter speed	0.0005 s
Display diagonal	3.5 \
Display resolution (numeric)	920000 pixels
Viewfinder type	Electronic
Viewfinder screen size	0.24 \
Camcorder type	Handheld camcorder
Image processor	DIGIC DV III
Minimum illumination	4.5 lx
Product color	Black
Video resolutions	1280 x 720, 1440 x 1080, 1920 x 1080 pixels
Maximum frame rate	60 fps
Video formats supported	MXF
Maximum video resolution	1920 x 1080 pixels
Maximum image resolution	- pixels
PCM digital audio	16-bit/48 kHz
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) out	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Battery voltage	7.4 V
Battery capacity	- mAh
Battery life (max)	- h
Video recording time	10.4 h
Operating temperature (T-T)	0 - 40 °C
Cables included	Component
Memory card included	CF
Video compression formats	MPEG2

Weight and Dimensions

Depth	250 mm
Width	121 mm
Height	148 mm
Weight	1290 g
