Special Recording Modes
86
4 Press the START/STOP button again to stop recording.
• All of the recorded frames are joined together into one clip.
• The tally lamps go out and [INT STBY] appears at the top of the screen (with [INT] flashing).
NOTES
• You can use only one special recording mode at a time.
• While recording, you cannot change the interval or number of frames.
• Some frames at the point the recording was stopped may be recorded and added to the end of the clip.
• Interval recording mode will be deactivated if the special recording mode is changed or turned off. It will be
deactivated also if you change the [J Other Functions] [Bit Rate/Resolution] or [Frame Rate] setting.
• The time code advances by the number of frames recorded. If the running mode of the time code (0 69) is
set to [Free Run] or the time code is input from an external source (b only), the running mode will switch
to [Rec Run] during special recording mode. When special recording mode is deactivated, the running mode
will return to its previous setting.
• b During special recording mode, the time code signal will not be output from the GENLOCK/TC
terminal or HD/SD SDI terminal.
Frame Recording Mode
Set the number of frames in advance. We recommend using the wireless controller or stabilizing the camcorder,
for example, on a tripod. Sound is not recorded in this mode. This mode is not available if [J Other Functions]
[Bit Rate/Resolution] is set to [35 Mbps 1440x1080].
Configuring Frame Recording Mode
1 Open the [Rec Frames] submenu.
[J Other Functions] [Frame Rec] [Rec Frames]
2 Select the desired number of frames and then press SET.
• Available options are 2, 6 and 12.
Activating Frame Recording Mode and Recording
1 Open the [Special Rec] submenu.
[J Other Functions] [Special Rec]
2 Select [Frame Rec] and then press SET.
• [FRM STBY] appears at the top of the screen (with [FRM] flashing).
3 Press the START/STOP button to begin recording.
• The camcorder automatically records the set number of frames.
• The tally lamps illuminate.
• [FRM STBY] changes to [N FRM REC] while recording frames and [N FRM STBY] when frames are not
being recorded.
• Repeat until you finish recording.
4 Open the [Special Rec] submenu.
[J Other Functions] [Special Rec]
[J Other Functions]
[Frame Rec]
[Rec Frames]
[2]
[J Other Functions]
[
Special Rec]
[Off]
COPY

Canon XF105 Specifications

General

Sensor type	CMOS
Total megapixels	2.37 MP
Optical sensor size	1/1.3 \
Effective megapixels (image)	2.07 MP
Filter size	58 mm
Digital zoom	- x
Optical zoom	10 x
Image stabilizer	Yes
Focal length range	4.25 - 42.5 mm
Interchangeable lens	-
Image stabilizer type	Optical Image Stabilization (OIS)
Minimum aperture number	1.8
Focal length (35mm film equivalent)	30.4 - 304 mm
Memory slots	2
Camcorder media type	Memory card
Disc types supported	No
Compatible memory cards	CF, SD
Maximum memory card size	128 GB
Internal storage capacity	- GB
Focus adjustment	Auto/Manual
Closest focusing distance	0.02 m
Camera shutter speed	0.0005 s
Display diagonal	3.5 \
Display resolution (numeric)	920000 pixels
Viewfinder type	Electronic
Viewfinder screen size	0.24 \
Camcorder type	Handheld camcorder
Image processor	DIGIC DV III
Minimum illumination	4.5 lx
Product color	Black
Video resolutions	1280 x 720, 1440 x 1080, 1920 x 1080 pixels
Maximum frame rate	60 fps
Video formats supported	MXF
Maximum video resolution	1920 x 1080 pixels
Maximum image resolution	- pixels
PCM digital audio	16-bit/48 kHz
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) out	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Battery voltage	7.4 V
Battery capacity	- mAh
Battery life (max)	- h
Video recording time	10.4 h
Operating temperature (T-T)	0 - 40 °C
Cables included	Component
Memory card included	CF
Video compression formats	MPEG2

Weight and Dimensions

Depth	250 mm
Width	121 mm
Height	148 mm
Weight	1290 g
