Canon XF105 - Configuring the Edge Monitor

Video Scopes
82
Configuring the Edge Monitor
Using this video scope allows you to focus with more precision when the
camcorder is in manual focus mode. The edge monitor features 2 modes.
1 Open the [Edge Monitor] submenu.
[J Other Functions] [WFM (LCD)] [Edge Monitor]
2 Select the desired option and then press SET.
Options
[Type 1]: The waveform that represents the focus of the entire picture is
displayed in green. In addition, the waveform of the area in the
three red frames is displayed in red on top of the previous
waveform.
[Type 2]: This mode displays the edge monitor with the waveform monitor
in [Line+Spot] mode. The waveform monitor appears on the left in
green while the edge monitor appears on the right in blue. The
waveform of the area in the red frame is displayed in red on top of
both green and blue waveforms.
[J Other Functions]
[WFM (LCD)]
[Edge Monitor]
[Type 1]
