Canon XF105 User Manual

65
Zooming
Using the Wireless Controller or Optional Remote Control
The zoom speeds when using the wireless controller and when using an optional (ZR-2000 or ZR-1000 Zoom
Remote Controller) or commercially available remote control connected to the REMOTE terminal are different.
When using the wireless controller, you must press the record enable button and desired zoom button
simultaneously to zoom.
Setting the Zoom Speed
Perform the following procedure to set the zoom speed for the supplied
wireless controller. Refer to the following table for a summary of zoom
speeds when using the wireless controller or other remote controls.
1 Open the zoom [Speed Level] submenu.
[l Camera Setup] [Zoom] [Speed Level]
2 Select [Fast], [Normal] or [Slow] and then press SET.
3 Open the zoom [Wireless Controller] submenu.
[l Camera Setup] [Zoom] [Wireless Controller]
4 Select the desired level and then press SET.
• This setting affects both the wireless controller and optional remote
controls.
Zoom speeds
Soft Zoom Control
Soft zoom control allows you to start and/or stop the zoom gradually.
1 Open the [Soft Zoom Control] submenu.
[l Camera Setup] [Zoom] [Soft Zoom Control]
2 Select the desired option and then press SET.
Options
Accessory Zoom speed
Wireless controller (supplied)
Constant zoom speed that is selected
from the menu.
Remote control without variable zoom speed
control (commercially available)
Constant zoom speed.
Remote control with variable zoom speed control
(optional ZR-2000 or ZR-1000 Zoom Remote
Controller, etc.)
Based on zoom speed setting of the
remote control.
[Both]: Zoom starts and stops gradually.
[Stop]: Zoom stops gradually.
[Start]: Zoom starts gradually.
[Off]: Use this setting if you do not intend to use soft zoom control.
[l Camera Setup]
[Zoom]
[Speed Level]
[Normal]
[l Camera Setup]
[Zoom]
[Wireless Controller 8]
[l Camera Setup]
[Zoom]
[Soft Zoom Control]
[Off]
COPY

Canon XF105 Specifications

General

Sensor type	CMOS
Total megapixels	2.37 MP
Optical sensor size	1/1.3 \
Effective megapixels (image)	2.07 MP
Filter size	58 mm
Digital zoom	- x
Optical zoom	10 x
Image stabilizer	Yes
Focal length range	4.25 - 42.5 mm
Interchangeable lens	-
Image stabilizer type	Optical Image Stabilization (OIS)
Minimum aperture number	1.8
Focal length (35mm film equivalent)	30.4 - 304 mm
Memory slots	2
Camcorder media type	Memory card
Disc types supported	No
Compatible memory cards	CF, SD
Maximum memory card size	128 GB
Internal storage capacity	- GB
Focus adjustment	Auto/Manual
Closest focusing distance	0.02 m
Camera shutter speed	0.0005 s
Display diagonal	3.5 \
Display resolution (numeric)	920000 pixels
Viewfinder type	Electronic
Viewfinder screen size	0.24 \
Camcorder type	Handheld camcorder
Image processor	DIGIC DV III
Minimum illumination	4.5 lx
Product color	Black
Video resolutions	1280 x 720, 1440 x 1080, 1920 x 1080 pixels
Maximum frame rate	60 fps
Video formats supported	MXF
Maximum video resolution	1920 x 1080 pixels
Maximum image resolution	- pixels
PCM digital audio	16-bit/48 kHz
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) out	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Battery voltage	7.4 V
Battery capacity	- mAh
Battery life (max)	- h
Video recording time	10.4 h
Operating temperature (T-T)	0 - 40 °C
Cables included	Component
Memory card included	CF
Video compression formats	MPEG2

Weight and Dimensions

Depth	250 mm
Width	121 mm
Height	148 mm
Weight	1290 g
