Canon XF105 User Manual

97
Custom Picture Settings
Editing a Custom Picture File’s Settings
1 After selecting a file, select [I X Edit File] and then press SET.
2 Select a setting and then press SET.
3 Change the setting to the desired level.
•Refer to Available Custom Picture Settings (0 99) for details on the various settings.
• Repeat steps 2 and 3 for other settings, as necessary.
4 Press the MENU button to exit the menu.
Renaming Custom Picture Files
1 After selecting a file, open the [Rename] submenu.
[I X Edit File] [Rename]
• A screen appears that displays the current file name with an orange
selection frame on the first character.
2 Select an alphanumeric character or symbol then move (A) to
the next field.
• Change the rest of the name in the same way.
3 Select [Set] and then press SET.
4 Press the MENU button to exit the menu.
Protecting Custom Picture Files
Protecting a custom picture file prevents its settings from being
accidentally changed.
1 After selecting a file, open the [Protect] submenu.
[I X Edit File] [Protect]
2 Select [Protect] and then press SET.
• In the file selection list, h will appear next to the file name.
• To remove protection settings, select [Unprotect] instead.
3 Press the MENU button to exit the menu.
Preset Custom Picture Files
By default, the custom picture files in the camcorder in file slots [C7] to [C9] are protected. Remove the
protection (0 97) to edit the file. The following describes when to use the preset files.
[C7 VIDEO.C]: For playing back video on consumer flat-panel displays.
[C8 CINE.V]: For achieving a cinema-like picture on TV monitors, such as when creating TV programs that
require a cinema-like effect.
[C9 CINE.F]: When combined with [Cine 2] (under [Gamma]) and [Cine 2] (under [Color Matrix] [Select]),
creates a cinema-like effect different from that of [C8 CINE.V].
[l Camera Setup]
[Custom Picture]
[I X Edit File]
[Rename]
[l Camera Setup]
[Custom Picture]
[I X Edit File]
[Protect]
COPY

Canon XF105 Specifications

General

Sensor type	CMOS
Total megapixels	2.37 MP
Optical sensor size	1/1.3 \
Effective megapixels (image)	2.07 MP
Filter size	58 mm
Digital zoom	- x
Optical zoom	10 x
Image stabilizer	Yes
Focal length range	4.25 - 42.5 mm
Interchangeable lens	-
Image stabilizer type	Optical Image Stabilization (OIS)
Minimum aperture number	1.8
Focal length (35mm film equivalent)	30.4 - 304 mm
Memory slots	2
Camcorder media type	Memory card
Disc types supported	No
Compatible memory cards	CF, SD
Maximum memory card size	128 GB
Internal storage capacity	- GB
Focus adjustment	Auto/Manual
Closest focusing distance	0.02 m
Camera shutter speed	0.0005 s
Display diagonal	3.5 \
Display resolution (numeric)	920000 pixels
Viewfinder type	Electronic
Viewfinder screen size	0.24 \
Camcorder type	Handheld camcorder
Image processor	DIGIC DV III
Minimum illumination	4.5 lx
Product color	Black
Video resolutions	1280 x 720, 1440 x 1080, 1920 x 1080 pixels
Maximum frame rate	60 fps
Video formats supported	MXF
Maximum video resolution	1920 x 1080 pixels
Maximum image resolution	- pixels
PCM digital audio	16-bit/48 kHz
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) out	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Battery voltage	7.4 V
Battery capacity	- mAh
Battery life (max)	- h
Video recording time	10.4 h
Operating temperature (T-T)	0 - 40 °C
Cables included	Component
Memory card included	CF
Video compression formats	MPEG2

Weight and Dimensions

Depth	250 mm
Width	121 mm
Height	148 mm
Weight	1290 g
